Ronix 4221 Quick Start Manual

Reciprocating saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RECIPROCATING SAW
4221

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4221 and is the answer not in the manual?

Questions and answers

Related Manuals for Ronix 4221

Summary of Contents for Ronix 4221

  • Page 1 RECIPROCATING SAW 4221...

  • Page 2: Technical Specifications

    TECHNICAL SPECIFICATIONS Model 4221 Voltage 220V Frequency 50Hz Power 705W No load speed 800~3000RPM Wood:115mm Cutting capacity Aluminum:20mm Steel: 10mm 1 pc blade for wood 1 pc blade for steel Accessories 1 pair of carbon brush 1 pc Instruction Manual...
  • Page 3 1) READ and become familiar with the entire Operator’s Manual. LEARN the tool’s application, limitations and possible hazards. 2) KEEP GUARDS IN PLACE and in working order. 3) REMOVE ADJUSTING KEYS AND WRENCHES. Form a habit of checking to see that keys and adjusting wrenches are removed from the tool before turning ON.
  • Page 4 14) DISCONNECT TOOLS before servicing; when changing accessories such as blades, bits, cutters, and the like. 15) REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure switch is in OFF position before plugging in. 16) USE RECOMMENDED ACCESSORIES. Consult the Operator’s Manual for recommended accessories.

  • Page 5: Cut-Off Machine Safety Warnings

    CUT-OFF MACHINE SAFETY WARNINGS - Hold power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
  • Page 6 - Always wait until the machine has come to a complete stop before placing it down. The tool insert can jam and lead to loss of control over the power tool. REPLACING/INSERTING THE SAW BLADE WARNING! When mounting the saw blade, wear protective gloves. Danger of injury when touching the saw blade.

  • Page 7: Dust/Chip Extraction

    hold. Remove the saw blade. DUST/CHIP EXTRACTION - Dusts from materials such as lead-containing coatings, some wood types, minerals and metal can be harmful to one’s health. Touching or breathing-in the dusts can cause allergic reactions and/or lead to respiratory infections of the user or bystanders.
  • Page 8 - Depending on the saw blade being used and the application, the footplate can be moved in length way direction in three steps. Press the release button for the footplate and slide the footplate to the required position. Release the footplate release button and check that the footplate is firmly latched.

  • Page 9: Switching On And Off

    NOTE: - If the tool is operated continuously at low speeds for a long period of time, the operation life of the motor will be reduced. - The speed adjusting dial can be turned only as far as full speed and lowest speed.
