2-2 Chapter 2: Installation and Wiring
Section 2.1
Prevent
Electrostatic
Discharge
WARNING
Section 2.2

EMC Directive

Section 2.3
Power Requirements
User's Manual Pub. 0300181-07 Rev. A
Industrial and Commercial Power Systems
Noise Reduction Techniques in Electronic Systems, by Henry W. Ott;
•
published by Wiley-Interscience of New York in 1976
Electrostatic discharge can damage integrated circuits or semiconductors if
you touch analog module card bus connector pins or the terminal block on
the module. Follow these guidelines when you handle the module:
Touch a grounded object to discharge static potential.
•
Wear an approved wrist-strap grounding device.
•
Do not touch the bus connector or connector pins.
•
Do not touch circuit components inside the module.
•
If available, use a static-safe workstation.
•
When it is not in use, keep the module in its static-shield bag.
•
This product is tested to meet Council Directive 2014/30/EU Electromagnetic
Compatibility (EMC) and the following standards, in whole or in part,
documented in a technical construction file:
EN 61000-6-4 Electromagnetic compatibility (EMC)–Part 6-4: Generic
•
standards–Emission standard for industrial environments.
• EN 61000-6-2 Electromagnetic compatibility (EMC)–Part 6-2: Generic
standards–Immunity for industrial environments.
UKCA Electromagnetic Compatibility Regulations 2016
BS EN 61131-2, BS EN 61000-6-4, BS EN 61000-6-2.
•
This product is intended for use in an industrial environment.
The module receives its power through the SLC-500 chassis backplane from the
fixed or modular +5 VDC and +24 VDC chassis power supply. The maximum
current drawn by the module is shown in the table below:
Model
1746sc-CTR8
1746sc-CTR4
Voltage (VDC) Current (mA)
5 225
24 125
5 175
24 75
