  • Page 1 VIESMANN Installation and service instructions for contractors Vitocom 100 Type GSM Remote monitoring and control of heating systems For applicability, see the last page VITOCOM 100 Please keep safe. 5862 947 GB 6/2006...
  • Page 2 Safety instructions Safety instructions Please follow these safety instructions closely to prevent accidents and material losses. Safety instructions explained the Code of Practice of relevant trade associations, Danger all current safety regulations as This symbol warns against the defined by DIN, EN, DVGW, TRGI, risk of injury.
  • Page 3 For replacements, use only ori- ginal spare parts from Viessmann or those which are approved by Viessmann.

  • Page 4: Table Of Contents

    Application ....................Installation sequence Installing the Vitocom 100 ................Inserting the SIM card ................. 10 Summary of electrical connections .............. 12 Connecting the Vitocom 100 ............... 15 Connecting additional signals ..............18 Power supply ....................20 Service instructions Commissioning Requirements ..................... 22 PIN code ....................

  • Page 5: Preparing For Installation Functions

    (like a mobile tele- phone). If you use equipment like this, please avoid the immediate vicinity of the Vitocom 100 if it is ready for operation. A Mobile phone D Control unit (see equipment B Text message centre of the mobile...
  • Page 6 Cost of a text message ing notification when faults occur Current language setting Remote scanning Your heating system is monitored by the Vitocom 100. The following are auto- matically signalled by text message via the mobile phone network: Heating system faults Note Expiry of SIM card (prepaid) The date "AKTDAT"...

  • Page 7: Selecting A Sim Card

    Bidirectional function PIN function A power failure or unplugging the Vitocom 100 from the power supply does not block the SIM card. The SIM card and therefore the Vitocom 100 are operational when the power is restored, without having to enter the PIN. Visual confirmation via the LED indicators on the unit (see pages 12 and 36 onwards).

  • Page 8: Installation Sequence

    Installation sequence Installing the Vitocom 100 Installation location The installation site must meet the fol- Install aerial in a suitable location: lowing criteria: To a suitable metal using the mag- Adequate reception quality (test net that is integrated in the aerial...
  • Page 9 Installation sequence Installing the Vitocom 100 (cont.) Wall mounting 1. Secure the retainer to the wall. 2. Slide housing onto the retainer.

  • Page 10: Inserting The Sim Card

    Installation sequence Installing the Vitocom 100 (cont.) 3. Bend up all 4 tabs to secure the unit. Inserting the SIM card Remove housing cover Please note Inserting a SIM card with the mains voltage applied can damage the unit or the SIM card.
  • Page 11 Installation sequence Inserting the SIM card (cont.) 1. Slide the metal slider of the SIM 3. Slide the SIM card into the holder card holder in the direction of the with contacts facing downwards. hinge ("OPEN"), thereby unlocking the holder. 4.

  • Page 12: Summary Of Electrical Connections

    Inserting the SIM card (cont.) 5. Slide the metal slider of the SIM 6. Check operation: card holder in the direction of the Connect the Vitocom 100 to the opening ("LOCK") thereby locking power supply. the holder. All 3 LED's permanently ON (for LED flashing pattern, see page 37).
  • Page 13 Installation sequence Summary of electrical connections (cont.) E 3 clips M SIM card holder F Green LED N Connector to lower PCB G Yellow LED O KM BUS connecting terminal H Red LED P GSM modem K Keys R Recess for strain relief at digital L PIN code rotary selector input with perforation Lifting off the upper PCB...
  • Page 14 Installation sequence Summary of electrical connections (cont.) Lower connecting level A KM BUS cable F Power supply connection terminal B Aerial cable with strain relief C Cable entry for 230 V~ digital G 230 V~ digital input connecting input terminal with strain relief (for additional unit) H Transformer D Power supply 230 V / 50 Hz...

  • Page 15: Connecting The Vitocom 100

    4. Connect the cable of the additional unit to the connecting terminal of the digital input. 5. Fit the grommet and screw on the strain relief upper part (pack). Connecting the Vitocom 100 Connection to the following control units: Control unit Type Vitotronic 150...
  • Page 16 Installation sequence Connecting the Vitocom 100 (cont.) A Vitocom 100 D Vitotronic 150, 200 or 300 B KM BUS distributor E Plugs aVG in Vitotronic 150, 200 (if required) or 300 C KM BUS cable, standard delivery F Connecting terminals 145 to the...
  • Page 17 Installation sequence Connecting the Vitocom 100 (cont.) Connection to the control units of the following wall mounted boilers: Connection to wall mounted boil- Type Vitodens 200 WB2A Vitodens 300 WB3A WB3B Vitodens 333 WS3A WS3B Vitodens 343 WS4A Vitopend 100...

  • Page 18: Connecting Additional Signals

    E Connecting terminals 145 to the C Wall mounted boiler Vitocom 100 Connecting additional signals Digital input Please note To prevent short circuiting or damage to the Vitocom 100: Check for phase equality with L1 of the power supply connec- tion of the Vitocom.
  • Page 19 On-site fault messages can be con- nected as 230 V~ volt signals via the digital input. The input signal is monitored by the Vitocom 100 and the fault is sig- nalled via text messaging. The text in the message can be indi- vidually specified.

  • Page 20: Power Supply

    Carry out the power supply connec- Protect the power supply cable to the tion and all earthing measures (i.e control unit or Vitocom 100 with a fuse fault current circuit) in accordance with a maximum rating of 16 A. with IEC 364, the requirements of your local electricity supply company and the VDE or local regulations.
  • Page 21 E Junction box (on-site) F Main isolator, two-pole, on-site (if installed) G Vitocom 100 Connection that is independent of the main isolator When the heating system is switched off via the main isolator, the Vitocom 100 continues to operate.

  • Page 22: Commissioning Requirements

    Commissioning Requirements A few details need to be entered to start up the Vitocom 100. This is done in the following steps: PIN code Note Commissioning text message with The Vitocom 100 is started up exclu- access code and language selec-...

  • Page 23: Pin Code

    Commissioning PIN code Enter PIN code with rotary selector and button...

  • Page 24: Entering Text Messages

    All entries apart from the PIN code are transmitted to the Vitocom 100 via mobile phone as text messages. Access code In addition to the PIN code of the SIM card in the Vitocom 100, the unit is also protected from abuse by an access code.
  • Page 25 Vitocom 100. Commissioning text message An initial text message must be transmitted in order to start the Vitocom 100. The commissioning text message Commissioning text message defines the mobile phone number for in English (en): incoming fault messages.
  • Page 26 Commissioning Entering text messages (cont.) Note It is advisable to enter the emergency If the commissioning text message is call number of a heating contractor or transmitted using the heating engi- service company as the second neer's mobile phone, the user's num- mobile phone number "MOBNR2".

  • Page 27: Configuration

    Configuration Text message commands with examples The user can transmit various commands and scans to the Vitocom 100 using text messages. The access code must always be at A reply message from the Vitocom the start of the text message.
  • Page 28 Configuration Text message commands with examples (cont.) Text messaging Description command SPRACHE Define language for text messages. Language options: de German fr French en English es Spanish Italian pl Polish hu Hungarian ru Russian Example: Reply test message (acknowl- Setting the language to German edgement) from the Vitocom 100: Text message from user:...
  • Page 29 Configuration Text message commands with examples (cont.) Text messaging Description command MOBNR2 Scan or modify mobile phone number 2: Enter max. 70 characters. The reply message is trans- mitted to the previous mobile phone number and the new one. Entry of the second mobile phone number is not man- datory.
  • Page 30 Configuration Text message commands with examples (cont.) Text messaging Description command (Constant temperature control unit) BAHKx Heating circuit operating mode x = 1, 2 or 3: Associated commands (appended with a space): DHW only (with frost protection) 1 to 4 Operation with standard room temperature and Standby mode (heating and DHW switched off, with frost protection) Example:...
  • Page 31 This entry is not required for a con- has now been restored. tract SIM card. However, to obtain The Vitocom 100 transmits the follow- information about a power failure, ing warning text message to enter a fictitious "AKTDAT" and "MOBNR1"...
  • Page 32 Resetting all settings to their delivered condition. The entire commissioning procedure must be repeated. Example: Text message from user: Deleting all previous settings, except 1111 RESET 1 SIM card PIN code Then another commissioning text message must be transmitted to the Vitocom 100 (see page 25).

  • Page 33: Special Instructions On Transmitting Text Messages

    As well as the above commands, other instructions and possibilities exist for transmitting text messages. Every text message received by the The following also applies: Vitocom 100 is acknowledged with a A space is always required between reply text message (confirmation or the access code and one or more error message).
  • Page 34 Configuration Special instructions on transmitting text . . . (cont.) Text message from user: Reply text message as confir- mation and error message: 1111 CODE 2345 MOBNR2 017198765432 BAHK4 0 2345 CODE 2345 OK MOBNR2 017198765432 OK BAHK4 0 ERROR...

  • Page 35: Credit Monitoring

    Credit monitoring SIM card validity The validity of the SIM card is monitored in the Vitocom 100 and provides secur- ity. Warning text messages are transmitted before the card expires. The access code and the "INFO" text (if specified) are preset.

  • Page 36: Led Indicators

    LED indicators LED indicators The Vitocom 100 has 3 LED's that indicate the following: Red LED Field strength indicator Yellow LED Connection set up indicator / Text message transmis- sion started Green LED Connection set up indicator / Text message transmis-...

  • Page 37: Troubleshooting

    Trigger a reset by briefly within 2 minutes pressing the button and making another attempt to dial in Fault messages Vitocom 100, type GSM fault messages: Code Fault Message text Digital input Digital input (DE1): 230V <EE text>...
  • Page 38 Troubleshooting Fault messages (cont.) The fault text message is transmitted to both mobile phone numbers "MOBNR1" and "MOBNR2" (if speci- fied). Example of a Vitotronic fault message: Code Fault Message text Outside temperature sensor fault Alarm-fault outdoor temp. 10 For a complete list of fault mes- sages, see installation/service instructions for the relevant control unit.

  • Page 39: Specification

    Specification Specification Rated voltage 230 V Rated frequency 50 Hz Power consumption Protection class Protection IP 41 to EN 60529, safeguard through appropriate design and installation Function Type 1 B as per EN 60730-1 Permiss. ambient temperature during operation 0 to +55 °C Installation in living spaces or boiler rooms (standard ambient conditions) 20 to +85 °C...

  • Page 40: Certificates

    Certificates Declaration of conformity We, Viessmann Werke GmbH & Co KG, D-35107 Allendorf, declare as sole responsible body that the Vitocom 100, type GSM product complies with the following standards: EN 50 090-2 2 EN 55 024 EN 50 165-1...
