Summary of Contents for OSS OSS-KIT-EXP-9000-2M
- Page 1 User Manual, PCIe x16 Gen 2 Expansion Kit OSS-KIT-EXP-9000-2M...
-
Page 2: Table Of Contents
2. Component Identification 2.a. Host cable adapter ..........................4 2.b. Target adapter ............................. 4 2.c. Specifications ............................5 2.d. OSS 2-slot backplane .......................... 5 3. Installation Instructions 3.a. Installing the adapter kit ........................6 3.b. Using the 2-slot backplane ........................6 3.c. -
Page 3: Description
PCIe slot of the server. It then cables to a downstream target adapter card. The target adapter card inserts in the OSS Gen 2, 2-slot backplane. The I/O board then inserts in the other slot of the backplane. -
Page 4: Component Identification
2. Component Identification 2.a. Host cable adapter The host adapter inserts into the host computer’s PCIe x16 slot. The host cable adapter (Part # OSS-PCIe-HIB25-x16-H) allows communication between a processor and an I/O point. Slot Cover (Also available in low profile... -
Page 5: Specifications
Redriver: Pericom PI2EQX5804 Agency Compliance: UL60950.FCC Class B, CE safety and emissions 2.d. OSS 2-slot backplane The 2-slot backplane can be installed in a separate enclosure to support the target adapter and an I/O card. Note: See section 4 Technical Information for slot pin outs. -
Page 6: Installation Instructions
Connect the PCIe cable to both the upstream host adapter and the downstream device. 3.d. Removing PCIe cable: To remove PCIe cable pull back on green thumb tab to release metal pins and gently separate. One Stop Systems OSS-KIT-EXP-9000-2M Specifications subject to change without notice Page 6... -
Page 7: Technical Information
4. Technical Information The transmit and receive signals on the OSS-HIB25-x16 are driven and conditioned by Pericom redriver chips. Adjustments can be made to equalization, de-emphasis and output swing. These controls are factory set by the use of zero Ohm resistors. In the following tables a 0 indicates that a zero Ohm resistor has been installed and a 1 indicates no resistor. -
Page 8: Pin Assignments
PERn2 PETp3 Ground Transmitter differential pair, PETn3 Ground Lane 3 Ground PERp3 Receiver differential pair, Lane 3 RSVD Reserved PERn3 PRSNT2# Hot-Plug presence detect Ground Ground RSVD Reserved One Stop Systems OSS-KIT-EXP-9000-2M Specifications subject to change without notice Page 8... - Page 9 Length of Zone A 21.54 ±0.13 Length of Zone B 5.00 ±0.13 Chamfer Width 0.30 ±0.05 Chamfer Length 1.00 ±0.05 Latch to Plug Body 1.60 ±0.13 Internal Plug Width 30.55 ±0.10 One Stop Systems OSS-KIT-EXP-9000-2M Specifications subject to change without notice Page 9...
- Page 10 X16 Connector Pin Outs: Target Slot Name Name +12V +12V +12V +12V +12V SMCLK REFCLK1+ SMDAT REFCLK1- +3.3V PS_ON# +3.3V 3.3Vaux +3.3V Mechanical WAKE# PERST# RSVD End of the REFCLK2+ One Stop Systems OSS-KIT-EXP-9000-2M Specifications subject to change without notice Page 10...
- Page 11 PETp7 PETn7 PERp7 End of the PRSNT_X8# PERn7 Connector PETp8 RSVD PETn8 PERp8 PERn8 PETp9 PETn9 PERp9 PERn9 PETp10 PETn10 PERp10 PERn10 PETp11 PETn11 PERp11 PERn11 PETp12 PETn12 End of the PERp12 PERn12 Connector One Stop Systems OSS-KIT-EXP-9000-2M Page 11...
- Page 12 End of the x1 Connector PERp1 RSVD PERn1 PETp1 PETn1 PERp2 PERn2 PETp2 PETn2 PERp3 PERn3 PETp3 RSVD PETn3 PRSNT_X4# End of the x4 RSVD Connector PERp4 RSVD PERn4 PETp4 PETn4 End of the x8 PERp5 Connector One Stop Systems OSS-KIT-EXP-9000-2M Page 12...
- Page 13 PERp9 PERn9 PETp9 PETn9 PERp10 PERn10 PETp10 PETn10 PERp11 PERn11 PETp11 PETn11 PERp12 PERn12 PETp12 PETn12 PERp13 PERn13 PETp13 PETn13 PERp14 PERn14 PETp14 PETn14 PERp15 PERn15 PETp15 End of the PRSNT_X16# PETn15 RSVD Connector One Stop Systems OSS-KIT-EXP-9000-2M Page 13...
-
Page 14: Ordering Information
5 Ordering Information OSS-KIT-EXP-9000-2M PCIe x16 Gen 2 expansion kit with PCIe x16 Gen 2 host cable adapter, PCIe x16 Gen 2 target cable adapter, PCIe 2-slot Gen 2 target backplane, and PCIe x16 2M cable. One Stop Systems OSS-KIT-EXP-9000-2M...
