Raption 150 Compact Installation Manual
4
A
Minimum distances
When installing the Charge Point, respect the minimum distances for maintenance
and safety reasons.
Please comply accordingly to your country specifications.
The next picture shows how it should be installed.
•
Do not install near areas where water or fluids can penetrate into the unit.
•
Do not install the Charge Point on unstable terrain.
(*) Respect the minimum lateral distance to allow proper circulation of air flow. This
unit has forced ventilation.
(**) If Bollard Impact Protector is installed, keep 900 mm as a minimum distance
in order to give enough space to open the frontal door of the Charge Point for
maintenance tasks.
11
1000
1000
