88 5689 991
Steamer Trunk Bar
A
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
B.
Side Panel
1 pc.
H.
Middle Panel
1 pc.

HARDWARE LIST

Caster
4 pcs.
Hex Wrench
1 pc.
For assembly see instructions in carton 88 5689 992
Tools Required For Assembly : Phillips screwdriver
C.
Side Panel
1 pc.
J.
Back Panel
1 pc.
Wood Screw
Cross Dowel
6 pcs. (+1 extra)
for Caster
16 pcs. (+2 extra)
Head Cap Bolt
Head Cap Bolt
(short)
(long)
4 pcs. (+1 extra)
6 pcs. (+1 extra)
Casual Attire For Today's Home
E.
Shelf
1 pc.
K.
Back Panel
1 pc.
M.
Door
1 pc.
Cam Lock Screw
20 pcs.(+1 extra)
Cam Lock
20 pcs.(+1 extra)
G.
Shelf
1 pc.
N.
Door
1 pc.
Wood Screw (long)
Door
for Drawer Side Part
8 pcs. (+1 extra)
Pull Handle
4 pcs.
Wood Screw (short)
for Drawer Base Part
Machine Screw
8 pcs. (+1 extra)
4 pcs.
