88 5537 991
The Lafayette
Bar Cabinet
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
A.
Top
1 pc.
E.
Base
1 pc.
F.
Plinth
1 pc.
Hardware List
Cam Lock Screw
Hex Wrench
1 pc.
17 pcs.(+1 extra)
Small
Hex Wrench
1 pc.
Head Cap Bolt
6 pcs. (+1 extra)
For assembly see instructions in carton 88 5537 992
Tools required for assembly : Phillips screwdriver
Magnet
2 pcs.
Cam Lock
Wood Screw (long)
17 pcs.(+1 extra)
16 pcs. (+1 extra)
Head Cap Bolt
Wood Screw (short)
for Leg
28 pcs. (+1 extra)
8 pcs. (+1 extra)
Casual Attire For Today's Home
P1.
Rack
2 pcs.
P2.
Rack
4 pcs.
M.
Center Shelf
1 pc.
Wood Screw
for Magnet
Adjustable Pin
4 pcs.(+1 extra)
20 pcs.(+1 extra)
Steel Plate
for Pull Handle
Attachment
1 pc.
Nail
2 pcs.(+1 extra)
H.
Back Panel
1 pc.
Machine Screw
Pull Handle
2 pcs.
2 pcs.
Pull Handle
Machine Screw
1 pc.
1 pc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles The Lafayette 88 5537 991
Summary of Contents for Home Styles The Lafayette 88 5537 991
- Page 1 88 5537 991 The Lafayette Bar Cabinet IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a Casual Attire For Today's Home...
- Page 2 88 5537 992 The Lafayette Bar Cabinet IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a Casual Attire For Today's Home...
- Page 3 Assembly Instructions 2/6 Magnet IMPORTANT You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. Figure 1 STEP 1 Attach 2X Magnets to Top (A) by using Wood Screws in the pre-drilled holes (see Figure 1).
- Page 4 Assembly Instructions 3/6 Figure 2 Cam Lock Cam Lock Screw STEP 3 Attach Front Rail (G) in between Middle Panels (D1) and (D2) with Cam Locks (see Figure 2). Attach Middle Panel (D1) and (D2) onto Base (E) with Cam Locks. Head Cap Bolt Figure 3 Cam Lock...
- Page 5 Assembly Instructions 4/6 STEP 5 Head Cap Bolt Slide Back Panels (H) and (I) into place. Cam Lock Place Top (A) onto the unit, using Cam Locks Adjustable Pin and Head Cap Bolts. Insert Adjustable Pins into side panels and middle panels at the desired level.
- Page 6 Assembly Instructions 5/6 Figure 4 Nail Figure 5 Steel Plate STEP 8 Attach Doors (J) and (K) by sliding the door lift hinges into the side panels lift hinges (See figure 4). Assemble Pull Handles to Doors (J) and (K) with Machine Screws.
- Page 7 Assembly Instructions 6/6 Drawer (Q) STEP 1 Attach Q1 to Q3 and Q4, using Phillips screwdriver long wood screws (4X) tighten halfway. Attach Q2 to Q3 and Q4 using long wood screws (4X) Figure 1 tighten halfway. (see Figure 1) MAKE SURE ROLLER IS ON THE BACK STEP 2...
