ROLLER ARM ASSEMBLY
KEY
QTY
PART NO.
1
1
500607
2
1
500508
3
1
500609
4
1
500610
5
1
500611
6
1
500612
7
1
500613
8
1
500614
9
1
430705
10
1
500616
11
1
500617
13
1
500619
14
1
500620
15
2
500495
16
3
500508
17
2
500621
18
1
500622
19
1
500505
20
1
500623
21
1
500624
22
3
500499
23
4
500563
24
2
500500
25
2
500625
26
2
500626
27
1
500627
28
1
430718
31
1
430719
DESCRIPTION
Tension Arm
Shaft
Connect Rod
Roller Arm
Shaft
Spring
Roller Shaft
Roller
Feed Spring
Washer
Nut
HBS, M6x75
HN, M6
HBS, M6x16
SW, M6
Bearing, 6001ZZ
Snap Ring S12
HSS, M5x5
HBS, M5x40
Bearing, 635ZZ
PW, M5
HN, M5
SW, M5
Snap Ring E6
Bushing
HBS, M5x30
Spacer
PW, M6 (C)
26
12/14/10
