Fischer Panda 15 mini PMS Digital Manual

Marine generator, 120 v/240 v - 60 hz / 16 kva, 230 v - 50 hz / 15 kva, super silent technology
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual Marine Generator
Panda 15 mini PMS Digital
120 V/240 V - 60 Hz / 16 kVA
230 V - 50 Hz / 15 kVA
Super silent technology
Panda_15mini_PMS_Digital_VCS183_eng.R03
12.8.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15 mini PMS Digital and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fischer Panda 15 mini PMS Digital

Summary of Contents for Fischer Panda 15 mini PMS Digital

  • Page 1 Manual Marine Generator Panda 15 mini PMS Digital 120 V/240 V - 60 Hz / 16 kVA 230 V - 50 Hz / 15 kVA Super silent technology Panda_15mini_PMS_Digital_VCS183_eng.R03 12.8.20...

  • Page 2: Current Revision Status

    Duplication and change of the manual is permitted only in consultation with the manufacturer! Fischer Panda GmbH, 33104 Paderborn, reserves all rights regarding text and graphics. Details are given to the best of our knowledge. No liability is accepted for correctness. Technical modifications for improving the product without previous notice may be undertaken without notice.

  • Page 3: Table Of Contents

    Panda Transport Box.......................... 24 3.2.1 Bolted Fischer Panda Transport Box .................. 24 3.2.2 Fischer Panda Transport Box with metal tab closure ............24 Transport and Loading/Unloading ...................... 24 3.3.1 Transporting the generator ....................24 3.3.2 Loading/unloading of the generator ................
  • Page 4 5.2.4 Protection conductor: ......................49 5.2.5 Operating control system on the Fischer Panda generator ..........49 Instructions for capacitors - not present at all models................. 49 Checks before start, starting and stopping the generator ..............49 6 Installation Instructions..........................
  • Page 5 Inhalt / Contens 6.4.3 Quality of the raw water sucking in line ................55 6.4.4 Generator installation above waterline ................56 6.4.5 Generator installation below waterline ................56 6.4.5.1 Raw water installation scheme................57 Installation of the water cooled exhaust system ................. 58 6.5.1 Installation of the standard exhaust system ..............
  • Page 6 Inhalt / Contens 7.6.1 Refilling oil .......................... 81 7.6.2 After the oil level check and refilling the oil ................. 82 Replacement of engine oil and engine oil filter ................... 82 7.7.1 After the oil change ......................84 Verifying the starter battery and (if necessary) the battery bank ............
  • Page 7 Inhalt / Contens 8.7.1 Rotor Magnetism Loss and „Re-magnetising“ ..............111 Engine Starting Problems ......................... 112 8.8.1 Electric Fuel Solenoid Valve .................... 112 8.8.2 Re-start with Failure Bypass Switch ................. 112 8.8.3 Lifting solenoid for motor stop - optional ................113 Check and discharge the capacitors....................
  • Page 8 Leere Seite / Intentionally blank Seite/Page 8 Kapitel/Chapter 1: 12.8.20...
  • Page 9 Not only do you have a Fischer Panda generator on board, you also have worldwide support from the Fischer Panda Team. Please take the time to read this and find how we can support you further.

  • Page 10: General Instructions And Regulations

    General Instructions and Regulations 1. General Instructions and Regulations 1.1 Safety first! These symbols are used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury of lethal danger during certain maintenance work or operations. Read these instructions carefully. Can cause acute or chronic health impairments or death WARNING: Hazardous materials even in very small quantities if inhaled, swallowed, or...
  • Page 11 General Instructions and Regulations General warning of a hazard area WARNING: General warning Can cause acute or chronic health impairments or death WARNING: Danger due to inhalation and/or even in very small quantities if inhaled or ingested. ingestion Warning of live parts that may cause electric shock upon WARNING: Risk of electric shock upon contact contact.

  • Page 12: Tools

    General Instructions and Regulations Wearing the applicable snugly fitting protective clothing MANDATORY INSTRUCTION: Wear snugly fitting provides protection from hazards and can prevent damage to protective clothing (PPE). your health. Wearing hearing protection provides protection from acute MANDATORY INSTRUCTION: Wear hearing and gradual hearing loss.
  • Page 13 General Instructions and Regulations Socket wrench set Hexagon socket wrench set Clamp-on ammeter (DC for synchronous generators; AC for asynchronous generators) Torque wrench 12.8.20 Kapitel/Chapter 1: General Instructions and Regulations - Seite/Page 13...

  • Page 14: Manufacturer Declaration In Accordance With The Machinery Directive 2006/42/Ec

    • You will receive free upgrades as necessary. Additional advantages: Based on your complete data record, Fischer Panda technicians can provide you with fast assistance, since 90 % of the disturbances result from defects in the periphery. Problems due to installation errors can be recognized in advance.

  • Page 15: Safety Instructions - Safety First

    General Instructions and Regulations 1.5 Safety Instructions - Safety First! 1.5.1 Safe operation Careful handling of the equipment is the best insurance against an accident. Read the manual diligently, and make sure you understand it before starting up the equipment. All operators, regardless of their experience level, shall read this manual and additional pertinent manuals before commissioning the equipment or installing an attachment.

  • Page 16: Safe Handling Of Fuels And Lubricants

    General Instructions and Regulations 1.5.5 Safe handling of fuels and lubricants Keep fuels and lubricants away from naked fire. Before filling up the tank and/or applying lubricant, always shut down the generator and secure it against accidental start-up. Do not smoke and avoid naked flame and sparking near fuels and the generator. Fuel is highly flammable and may explode under certain conditions.

  • Page 17: Safety Precautions Against Burns And Battery Explosions

    General Instructions and Regulations 1.5.7 Safety precautions against burns and battery explosions The generator and its cooling agents and lubricants as well as the fuel can get hot while the generator is operated. Use caution around hot components such as parts containing exhaust fumes, radiator, hoses, and engine block during operation and after the generator was shut down.

  • Page 18: Implementation Of Safety Inspections And Maintenance

    General Instructions and Regulations 1.5.10 Implementation of safety inspections and maintenance Disconnect the battery from the engine before performing service work. Affix a sign to the control panel - both the main and the corresponding slave panel - with the instruction “DO NOT START UP - MAINTENANCE IN PROGRESS“...

  • Page 19: Protective Conductor And Potential Equalisation

    General Instructions and Regulations 1.6.1.1 Protective conductor and potential equalisation: Electric voltage above 50 V may be life-threatening. Fort this reason systems are grounded with a protective conductor. In connection with a RCD the current supply will be disconnected in case of a failure. Appropriate safety precautions like the RCD and corresponding fuses have to be provided by the customer to guarantee a save operation of the generator.

  • Page 20: Safety Instructions Concerning Cables

    • Battery connection cables shall be installed with utmost care and shall be checked for excessive heating under load. Check the battery near vibrating components regularly for chafing and insulation defects. ATTENTION! For battery charger generators (Fischer Panda AGT-DC)! Prior to installation, verify that the voltage of the battery bank complies with the output voltage of the generator.

  • Page 21: In Case Of Emergency First Aid / Im Notfall - Erste Hilfe

    In case of Emergency First Aid / Im Notfall - Erste Hilfe 2. In case of Emergency First Aid / Im Notfall - Erste Hilfe First Aid in case of accidents by electrical shocks 5 Safety steps to follow if someone is the victim of electrical shock Do not touch the injured person while the generator is running.

  • Page 22: When An Adult Stops Breathing

    In case of Emergency First Aid / Im Notfall - Erste Hilfe 2.1 WHEN AN ADULT STOPS BREATHING DO NOT attempt to perform the rescue breathing Warning: techniques provided on this page, unless certified. Performance of these techniques by uncertified personnel could result in further injury or death to the victim.

  • Page 23: Basics

    This manual is work instruction and operation instruction for the owner and user of Fischer Panda generators. The manual is the base and the guideline for the correct installation and maintenance of Fischer Panda Generators. The manual does not substitute the technical evaluation and should be used as an example guide only.

  • Page 24: Panda Transport Box

    3.3.1 Transporting the generator • The generator must always be upright for transport. • For transport, the Fischer Panda Transport Box shall be used for the generator. The generator shall be securely attached to the bottom of the box. • For loading/unloading, an adequate industrial truck shall be used.

  • Page 25: Scope Of Delivery

    An adequate lifting yoke shall be used for transport/ Fig. 3.3-1: Lifting yoke (example) loading 3.4 Scope of delivery The Fischer Panda PMS generator system contains following components: 3.4.1 Asynchronous Generator: Fischer Panda Generator Fig. 3.4-1: Fischer Panda Generator representative picture Remote control panel Fig.
  • Page 26 AC Control Box is not required for this generators. representative picture Fischer Panda Manual Fig. 3.4.1-4: Fischer Panda Manual The Fischer Panda Manual contains following components: • Clear foil bag with general informations ect. • Generator manual with added remote control panel manual •...

  • Page 27: Opening The Mpl Sound Insulation Capsule

    Basics 3.4.2 Opening the MPL sound insulation capsule To open the sound insulation capsule, the closures must Fig. 3.4-1: Sound insulation capsule, side part be rotated roughly 180° counter-clockwise. Use a flat head screwdriver. Pull the sidewalls out by gripping into the slots.

  • Page 28: Opening The Gfk Sound Insulation Capsule

    Basics 3.4.3 Opening the GFK sound insulation capsule GFK sound insulation capsule with lash closures Fig. 3.4-1: Lash closures To open the lash closures pull the handle in arrow Fig. 3.4-2: Lash closures direction and lift the lash of the closure pin. After lifting of the lashes, the sound isolation cover upper pars can be removed.

  • Page 29: Reference Note For The Starter Battery At A Long-Term Standstill

    For a 24 V battery applies 23,4 V lower open-circuit voltage (battery flat) - conservation charging 26,4 V. These data relate to a battery temperature of 20-25 °C. Consider the specifications of the battery manufacturer. Fischer Panda recommendation: Notice: • Install a battery main switch and turn it to the off-position.

  • Page 30: Arrangements For Deconservation After A Medium-Term Standstill (3 To 6 Months)

    Basics • Check anti-freeze protection of the cooling water and refill if applicable. The anti-freeze protection should not be older than 2 years. The content of the anti-freeze protection should be between 40% and 60% to ensure corrosion protection in the cooling water circuit; Refill anti-freeze if necessary. If cooling water will be drained, for example after a conservation of the engine, no water should remain within the engine during the stand still.

  • Page 31: Arrangements At A Long-Term Standstill / Shutdown

    Basics • Visual inspection of the generator according to initial operation and start generator. 3.5.4 Arrangements at a long-term standstill / shutdown Standstill (more than 6 months) 3.5.4.1 Arrangements for conservation: • Check the charge of battery and recharge approximately every 3 months if necessary. Consider the specifications of the battery manufacturer.

  • Page 32: Arrangements After A Long-Term Standstill (Shutdown) / Recommissioning (More Than 6 Months)

    • Keep shut-off lever at generator in 0-position and activate starter for approx. 10 sec. Make a break for 10 sec. and repeat procedure twice. • Visual inspection of the generator according to initial operation and start generator. Fischer Panda recommendation: Notice: After a long-term standstill a complete 150 h inspection according to inspection schedule should be carried out.

  • Page 33: The Panda Generator

    The Panda Generator 4. The Panda Generator 4.1 Type plate at the Generator Fig. 4.1-1: Type plate Fig. 4.1-2: Discription type plate 12.8.20 Kapitel/Chapter 4: The Panda Generator - Seite/Page 33...

  • Page 34: Description Of The Generator

    The Panda Generator 4.2 Description of the Generator 4.2.1 Right Side View Fig. 4.2.1-1: Right Side View Thermostat housing Solenoid switch for starter motor Pulley V-Belt Starter motor V-belt for cooling water pump Thermo-sensor raw water Oil pressure switch/sensor Exhaust out Engine oil filter Freshwater return pipe Sound cover - base part...

  • Page 35: Left Side View

    The Panda Generator 4.2.2 Left Side View Fig. 4.2.2-1: Left Side View Excitation capacitors Raw water pump Air suction housing with air filter Raw water intake hose Failure bypass switch Fuel filter Air suction hose to induction elbow Raw water filter (Impellerfilter) Stop solenoid Fuel stop solenoid Pulley for internal cooling water pump...

  • Page 36: Front View

    The Panda Generator 4.2.3 Front View Fig. 4.2.3-1: Front View 13 14 Ventilation screw thermostat housing Raw water inlet Thermostat housing with thermostat set Fuel intake connection Pulley for internal cooling water pump Fuel backflow connection Pully V-Belt Oil drain hose V-belt internal cooling water pump Cable fuel pump Raw water pump...

  • Page 37: Back View

    The Panda Generator 4.2.4 Back View Fig. 4.2.4-1: Back View Excitation capacitors Cooling water connection block Air filter housing with air filter element Cover for oil-cooled bearing Boost capacitors Connection for external expension tank Generator front cover Connection external ventilation valve 12.8.20 Kapitel/Chapter 4: The Panda Generator - Seite/Page 37...

  • Page 38: Details Of Functional Units

    The Panda Generator 4.3 Details of functional units 4.3.1 Remote control panel The remote control panel is equipped with some new monitoring functions, which increases the operational safety of the generator. A failure message is shown over contacts which are normaly closed. If a connection is intermitted triggers this a failure message.
  • Page 39 The Panda Generator Fig. 4.3.1-2: Cooling Circuit - Schema 12.8.20 Kapitel/Chapter 4: The Panda Generator - Seite/Page 39...

  • Page 40: Fuel System - Schema

    The Panda Generator 4.3.2 Fuel System - Schema Fig. 4.3.2-1: Fuel System - Schema Seite/Page 40 - Kapitel/Chapter 4: The Panda Generator 12.8.20...

  • Page 41: Sensors And Switches For Operating Surveillance

    The Panda Generator 4.3.3 Sensors and switches for operating surveillance Thermo-sensor at cylinder head Fig. 4.3.3-1: Thermo-switch at cylinder head The thermo-sensor at the cylinder head serves the monitoring of the generator temperature. Thermo-switch in the generator coil Fig. 4.3.3-2: Coil thermo-switch 1.
  • Page 42 The Panda Generator Thermo-sensor mixing elbow Fig. 4.3.3-4: Thermo-sensor mixing elboe Thermo-sensor water in Fig. 4.3.3-5: Thermo-sensor water in Thermo-sensor exhaust Thermo-sensor fresh water in Thermo-sensor fresh water out Oil pressure sensor Fig. 4.3.3-6: Oil pressure sensor In order to be able to monitore the lubricating oil system, an oil pressure sensor is built into the system.
  • Page 43 The Panda Generator Fig. 4.3.3-7: The Oil Circuit - Schema 12.8.20 Kapitel/Chapter 4: The Panda Generator - Seite/Page 43...

  • Page 44: Operation Instructions

    The Panda Generator 4.4 Operation instructions 4.4.1 Preliminary remark Fischer Panda recommends normal starter battery use. If a Tips regarding Starter Battery genset is required for extreme winter conditions, then the starter battery capacity should be doubled. It is recommended that the starter battery be regularly charged by a suitable battery-charging device (i.e., at least every 2...
  • Page 45 The Panda Generator 7. Check the Motor and Generator Mounting Screws are Tight. The mounting screws must be checked regularly to ensure the generator is safe. A visual check of these screws must be made, when the oil level is checked. 8.
  • Page 46 The Panda Generator Leere Seite / Intentionally blank Seite/Page 46 Kapitel/Chapter 4: The Panda Generator 12.8.20...

  • Page 47: Generator Operation Instruction

    Generator operation instruction 5. Generator operation instruction 5.1 Personal requirements Only instructed persons are allowed to run the generator. Instructed Persons has read the manual of the generator and all ancillary components and external equipment. He must be acquaint with the specific risks and safety instructions.

  • Page 48: Pre-Heating The Diesel Motor

    It is harmless for the generator to deliver full nominal power for 2-3 hours. The hole conception of the Fischer Panda generator make sure, that the full power operation at extreme condition will not increase the engine temperatures over. Please note that the emissions of the generator also increase at full power operation.

  • Page 49: Protection Conductor

    5.2.5 Operating control system on the Fischer Panda generator Fischer Panda generators are equipped with various sensors/temperatures switches. The combustion engine is further equipped with a oil pressure control switch, which switches the motor off, if the oil pressure sinks to a particu- lar level.
  • Page 50 Generator operation instruction Leere Seite / Intentionally blank Seite/Page 50 Kapitel/Chapter 5: Generator operation instruction 12.8.20...

  • Page 51: Installation Instructions

    6.1 Personal requirements The described installation must be done by a technical trained person or a Fischer Panda service point. 6.1.1 Hazard notes for the installation Follow the general safety instruction at the front of this Notice! manual.
  • Page 52 Installation Instructions Oil and fuel vapours can ignite at contact with ignition Warning! Danger of fire sources. Therefore: • No open flames during work on the generator. • Do not smoke. • Remove oil and fuel residues from the generator and floor. Contact with engine oil, antifreeze and fuel can result in Danger! Danger of poisoning damage to health.

  • Page 53: Place Of Installation

    Installation Instructions 6.2 Place of installation 6.2.1 Preliminary remark • There must be sufficient fresh air supply for the combustion air. • It has to be ensured that the cooling air supply from underneath or sidewise is sufficient. • During operation the sea cock has to be opened. •...

  • Page 54: Advice For Optimal Sound Insulation

    6.3 Generator Connections Sample for the connection at the Fischer Panda generator. See the description of the generator for the original loca- tion. All electrical wires are connected within the capsule tightly to the motor and the generator. This is also the case for fuel lines and cooling water lines.

  • Page 55: Installation Of The Cooling System - Raw Water

    Installation Instructions Fig. 6.3-2: Connection at the Generator - sample 1) External cooling water expansion tank Example - see section 5.2 for detailed information 2) External ventilation valve 6.4 Installation of the cooling system - raw water 6.4.1 General information The genset should have its own raw water (coolant water) inlet and should not be connected to any other engine systems.

  • Page 56: Generator Installation Above Waterline

    In this case the impeller should be removed out of the impeller pump. Contact Fischer Panda for further information. Never change the impeller for many years, without NOTE: exchanging the old pump.

  • Page 57: Raw Water Installation Scheme

    Installation Instructions Fig. 6.4.5-2: Rubber hose for vent valve - example The rubber hose for the external vent valve will be cut..and bend upwards. Fig. 6.4.5-3: Split rubber hose for vent valve Both hose ends will be extended respectively with a hose and connected with a vent valve 600 mm over the waterline.

  • Page 58: Installation Of The Water Cooled Exhaust System

    Installation Instructions 6.5 Installation of the water cooled exhaust system 6.5.1 Installation of the standard exhaust system The generator exhaust system must remain completely independent and separate from the exhaust system of any other unit(s) on board. The water lock must be installed at the lowest point of the exhaust system. An optional noise insulated water lock can also be installed.

  • Page 59: Possible Cause For Water In The Exhaust Hose

    Installation Instructions If the waterlock is arranged in an unfavourable position, the cooling water flowing back in the exhaust hose can rise so high, that it reaches the exhaust stack. Since at least one discharge valve is always open when the engine is shut off, the sea water has free access to the combustion chamber.

  • Page 60: The Volume Of The Waterlock

    Installation Instructions The picture below shows that the distance between the critical point at the exhaust elbow and the maximum permissible water level in the exhaust hose is stated with 600 mm. This distance should be understood as a minimum distance. 6.6.3 The volume of the waterlock The waterlock must be measured so large, that it can take the entire amount of water flowing back from the exhaust hose.
  • Page 61 Installation Instructions In Fig. 6.6.3.1-1, the waterlock is mounted in center Fig. 6.6.3.1-1: Ideal position of the waterlock underneath the generator. When the ship tilts, the position of the waterlock related to the critical point at the exhaust hose, changes only slightly. Tilted position 15 degrees - Fig.

  • Page 62: Example Of The Installation Of The Waterlock Off-Center And Possible Effects

    Installation Instructions Summary: The preset minimum height of 600 mm must be regarded unconditionally and is only valid if the waterlock is mounted in its ideal position in center underneath the generator. A higher position is highly recommended if it has to be reckoned with tilted positions of 45 degrees.

  • Page 63: Exhaust / Water Separator

    In order to reduce the noise level of the generator unit to a minimum, an optional exhaust outlet muffler can be mounted next to the through-hull fitting. Additionally there is a component at Fischer Panda, which acts as both an „exhaust goose neck“, and water separator.

  • Page 64: Installation Exhaust Water Separator

    Installation Instructions Fig. 6.7-1: Installation Scheme exhaust / water separator 6.8 Installation exhaust water separator If the exhaust water separator was sufficiently highly installed, a goose neck is no longer necessary. The exhaust/ water separator fulfils the same function. If the „Super silent“ exhaust system were installed correctly, the generator will not disturb your boat neighbour.

  • Page 65: Fuel System Installation

    The external Fuel pump should be installed near the tank. Electrical fuel pump Fig. 6.9.1-1: electrical fuel pump With the Fischer Panda generator is usually supplied an external, electrical fuel pump (DC). The fuel pump must be installed close at the fuel tank. The electrical connections is prepared at the generator.

  • Page 66: Connection Of The Fuel Lines At The Tank

    Fischer Panda Fuel Prefilter System 1S Maßstab: 1 : 6,5 Gewicht: Fischer Panda Material: Geprüft und Art.-Nr.: 3D-Nr.: FP1-305390 Fischer Panda GmbH Otto-Hahn-Str. 40 D-33104 Paderborn Tel.: 05254/9202-0 Fax (05254) 9202-550 info@fischerpanda.de www.fischerpanda.de Kraftstoff-Filtration / Fuel filtration Datum Name freigegeben zur sbergmann Bearbeiter 24.06.2020...

  • Page 67: Position Of The Pre-Filter With Water Separator

    6.9.3 Position of the pre-filter with water separator Additionally to the standard fine filter a prefilter with Fig. 6.9.3-1: Fischer Panda Fuel Prefilter S1 with water separator water separator must be installed outside of the sound insulation capsule in the fuel system line (not included in the delivery).
  • Page 68 Installation Instructions batteries in a row) To avoid large voltage drops the battery should be NOTE: installed as near as possible to the generator. The positive terminal of the battery is attached at the red cable, the negative pole at the blue cable. A t t e n t i o n ! : C o n s i d e r c o r r e c t c o n n e c t i o n It must be guaranteed that first the cables are attached at the sequence...
  • Page 69 Installation Instructions Negative battery cable Fig. 6.10.1-2: Negative Battery Cable The negative (-) battery cable is connected to the engine foot. Note! The battery negative pole may not be connected with the boat ground or with the protective grounding of the 120 V installation! DC-Relay Fig.
  • Page 70 Installation Instructions Fig. 6.10.1-5: Connection starterbattery 12 V - schema 1. Generator 3. Fuse 2. Battery block 4. Battery main switch Fig. 6.10.1-6: Connection starterbattery 24 V - schema 1. Generator 3. Fuse 2. Battery block 4. Battery main switch Seite/Page 70 - Kapitel/Chapter 6: Installation Instructions 12.8.20...

  • Page 71: How To Connect Two 12 V Batteries To A 24 V Battery Bank

    Installation Instructions 6.10.2 How to connect two 12 V batteries to a 24 V battery bank The starter batteries have to be connected in this order: Fig. 6.10.2-1: Installation starter battery 1. (+) cable of first battery 2. (-) cable of second battery Fig.

  • Page 72: Connection Of The Remote Control Panel - See Separate Control Panel Manual

    Installation Instructions 4. (-) cable of first battery Fig. 6.10.2-4: Installation starter batterie Disconnect the batteries in in reverse procedure. 6.10.3 Connection of the remote control panel - see separate control panel manual 6.11 Generator AC System Installation Before the electrical system is installed, READ the Warning!: Electrical Voltage SAFETY INSTRUCTIONS of this manual FIRST! Be sure that all electrical installations (including all safety...
  • Page 73 Installation Instructions represantive picture Fig. 6.11.2-1: AC-Control box 1 Grounding point at the AC-Control box 2 Label for mounting direction at the AC-Control box The AC-Control box is necessary for the operation of Panda generators. According to the generator capacity the AC Control box is variable dimensioned and equipped.

  • Page 74: Connection To The Ac On-Board Power Supply

    Installation Instructions Boost relay (not all models) Fig. 6.11.2-3: Boost relay Additionally, the automatic start booster is mounted at the generator or inside of the AC-Control box. The starting current is increased by connecting a second group of capacitors, if the voltage drops below a pre-set voltage.

  • Page 75: Disconnector - Power Source Selector (Three Way Cam Switch)

    If a proper break is the cause, this may lead to considerable damages at the generator. To prevent this, Fischer Panda offers a water sensor in his accessories program, which may be installed in the generator. This sensor identifies the flooding and switches the generator off. The sensor should be installed as close as possible to the capsule floor.

  • Page 76: Instructions And Measures On Prevention Of Galvanic Corrosion

    Installation Instructions 6.13.1 Instructions and measures on prevention of galvanic corrosion Several measures must be considered when making the installation so that galvanic corrosion can be avoided as much as possible: • Separation of the water column (between raw water and generator) after shutdown. This can either be a stop vlave turned by hand (Attention! The valve must be closed after each operation) or by the installation of an automatic ventilation valve.

  • Page 77: Maintenance Instructions

    The maintenance described here can be carried out by the operator unless otherwise indicated. Further maintenance work may only be carried out by specially trained specialist personnel or authorized repairers (Fischer Panda Service Points). This is especially true for work on the valve setting, diesel injection system and for engine repair.
  • Page 78 Maintenance Instructions Oil and fuel vapours can ignite on contact with ignition Warning!: Danger of fire sources. Therefore: • No open flames during work on the generator. • Do not smoke. • Remove oil and fuel residues from the generator and floor. Contact with engine oil, antifreeze and fuel can result in Danger! Danger of poisoning damage to health.

  • Page 79: Environmental Protection

    Maintenance Instructions Observe the instructions from your battery manufacturer. The different liquid systems (Cooling System, Fuel system WARNING: System may be pressurised! etc. may pressurised after operation. When the system is opened, the pressure can be relieved abruptly and expel hot gases and fluids.

  • Page 80: Check Of Hoses And Rubber Parts In The Sound Insulated Capsule

    Maintenance Instructions Maintenance intervals - see separate data sheet 7.4.2 Check of Hoses and Rubber Parts in the sound insulated capsule Check all hoses and hose connections for good condition. The rubber hoses are very sensitive to environmental influences. They wear out quickly in an environment of dry air, oil and fuel vapours, and high temperatures. The hoses must be checked regularly for elasticity.

  • Page 81: Refilling Oil

    • if the oil-level is under the minimum mark by less than 50h, there might be a technical problem! In that case, we recommend going to a shop or a Fischer Panda service point. • if the oil is cloudy or even „creamy“, coolant might have mixed with the oil. See a garage or a Fischer Panda service point immediately.

  • Page 82: After The Oil Level Check And Refilling The Oil

    Maintenance Instructions If oil-level is still too low (under 2/3): repeat steps 4-6. 7.6.2 After the oil level check and refilling the oil • Put the oil dipstick back into the check rail. • Close the oil filling cap. • Remove potential oil stains and splashes from the generator and surroundings. •...
  • Page 83 Maintenance Instructions - with generators that have an external oil drain hose: Release the oil drain hose from the mounting. - with generators that have an internal oil drain hose: Open the lead-through for the oil drain hose (left turn of the sealing).

  • Page 84: After The Oil Change

    Maintenance Instructions Oil screen with generators with EA300 engines Fig. 7.7-4: Oil screen The oil screen should be cleaned every 500 operating hours: to do so follow the instructions in the engine manual. Use spanner size 17 mm. Sample picture 6.

  • Page 85: Verifying The Starter Battery And (If Necessary) The Battery Bank

    Maintenance Instructions 7.8 Verifying the starter battery and (if necessary) the battery bank Check the condition of the battery. Proceed here as prescribed by the battery manufacturer. If from the battery manufacturer not otherwise mentioned. 7.8.1 Battery 7.8.1.1 Check battery and cable connections •...

  • Page 86: Check Electrolyte Density

    Maintenance Instructions 7.8.1.3 Check electrolyte density • Measure the electrolyte density of individual cells with a Fig. 7.8.1.3-1: Battery commercial hydrometer. The hydrometer reading (see table on following page) indicates the battery’s state of charge. During measurement, the temperature of the electrolyte should preferably be 20 °C.

  • Page 87: Checking The Water Separator In The Fuel Supply

    Maintenance Instructions 7.9 Checking the water separator in the fuel supply The pre-filter with water separator has a cock underneath, by Fig. 7.9-1: Pre-filter with water separator which means the water can be drained. This water sinks to the bottom, due to the difference in the densities of water and fuel.

  • Page 88: Alternative Replacement Of The Air Filter Mat With Pull Out Holder

    Maintenance Instructions 7.9.2 Alternative replacement of the air filter mat with pull out holder 1. Air filter housing with pull out holder. Fig. 7.9.2-1: Air suction housing with pull out holder 2. Tip the two fasteners 90°. Fig. 7.9.2-2: Air suction housing with pull out holder 3.
  • Page 89 Maintenance Instructions 4. Replace the air filter mat. Fig. 7.9.2-4: Air suction housing with pull out holder 5. Re-assembly in reversed order. 12.8.20 Kapitel/Chapter 7: Maintenance Instructions - Seite/Page 89...

  • Page 90: Alternative Replacement Of The Air Filter At Housing With Snap Fasteners

    Maintenance Instructions 7.9.3 Alternative replacement of the air filter at housing with snap fasteners 1. Open the combustion air housing by loosening the closure Fig. 7.9.3-1: Air suction housing on the right side of the housing. 01. Closure 2. Open the combustion air housing by loosening the closure Fig.

  • Page 91: Ventilation Of The Coolant Circuit / Freshwater

    Maintenance Instructions 7.9.4 Ventilation of the coolant circuit / freshwater Special notes for the ventilation of the cooling system Attention If the cooling water is drained, or if other air has entered the cooling system, it is necessary to ventilate the cooling system.
  • Page 92 Maintenance Instructions 2. Open the ventilating screw on the thermostat casing. Fig. 7.9-3: Ventilating screw on the thermostat housing Use spanner size 10 mm. 3. Pour cooling water into the cooling water filling necks. Fig. 7.9-4: Cooling water filler cap (At generators without filler, The cooling water can be filled into the external expansion tank instead) 4.

  • Page 93: V-Belt Replacement For The Internal Cooling Water Pump

    Maintenance Instructions 7.9.5 V-belt replacement for the internal cooling water pump The V-belt wears in a short time due to high ambient temperature within the closed capsule (approx. 85 °C). The air in the generator capsule is not only warm but also very dry. Therefore it is possible, that the „softener“ in the rubber composers wear after a very short time of operation.
  • Page 94 Maintenance Instructions 3. The alternator must be pressed in the direction of the Fig. 7.9.5-3: Alternator thermostat housing. 4. Exchange the V-belt. Sample Picture 5. Afterwards, the V-belt must be tightened again. Fig. 7.9.5-4: V-belt 6. The V-belt must be tightened in such a way, that it is possible to press it about approx.

  • Page 95: The Raw Water Circuit

    Maintenance Instructions 7.10 The raw water circuit 7.10.1 Clean raw water filter The raw water filter should be released regularly from Fig. 7.10.1-1: Raw water filter arrears. In each case the water cock must be closed before. It is mostly sufficient to beat the filter punnet. If water should seep through the cover of the raw water filter, this may be sealed in no case with adhesive or sealant.

  • Page 96: Replacement Of The Impeller

    Maintenance Instructions 7.11.1 Replacement of the impeller Close the raw water stop cock. Fig. 7.11.1-1: Raw water cock Representative picture Raw water pump on the front side of the genset. Fig. 7.11.1-2: Raw water pump Representative picture Remove the cover of the raw water pump by loosen the Fig.

  • Page 97: Check And Discharge The Capacitors

    Maintenance Instructions Fig. 7.11.1-4: Impeller pump Pull to the impeller with a multigrip pliers of the wave. Mark the impeller, to make sure that these is used in the correct position at re-installation. Representative picture Check to the impeller for damage and replace it if Fig.
  • Page 98 Maintenance Instructions have been removed, the capacitors must be discharged by bridging the capacitor terminals with a discharge reactor. The capacitors can be checked using a multimeter with capacitor measuring. The capacitors fitted inside the cabinet are discharged over the soldered resistor at every capacitor. The discharge over the discharge reactor (see special tools) is security because the capacitor voltage is lethal.
  • Page 99 Maintenance Instructions The capacitors should not be removed from the electrical cabinet before the check is made. Checking the electrical connections to the Capacitor It must be ensured that the electrical connections to the capacitor are always tight fitting. Loose connections with transitional resistance can mean that the contact surfaces will become heated externally.
  • Page 100 Maintenance Instructions Leere Seite / Intentionally blank Seite/Page 100 - Kapitel/Chapter 7: Maintenance Instructions 12.8.20...

  • Page 101: Generator Faults

    Generator Faults 8. Generator Faults 8.1 Personal requirements The work described here, unless otherwise indicated, are performed by the operator. Any further repair work may be performed only by specially trained personnel or by authorized repair shops (Fischer Panda service points). This is especially for working on the valve timing, fuel injection system and the engine repair. 8.2 Hazard notes for this chapter see “Safety first!”...

  • Page 102: Tools And Measuring Instruments

    Generator Faults Contact with engine oil, antifreeze and fuel can result in Danger!: Danger of poisoning damage to health. Therefor: • Avoid skin contact with engine oil, fuel and antifreeze. • Remove oil and fuel splashes and antifreeze from the skin immediately.

  • Page 103: Troubleshooting Table And Flowchart

    Generator Faults 8.4 Troubleshooting Table and Flowchart 8.4.1 Generator output voltage too low Cause Solution Generator is overloaded. Reduce the electrical load (switch off load) Motor is not reaching the rated rpm. Refer to „motor faults“ section. Defective capacitor(s). Check capacitors and replace if necessary. 8.4.2 Generator voltage too high Cause Solution...

  • Page 104: Motor Does Not Achieve Enough Speed During Starting Process

    Generator Faults 8.4.7 Motor does not achieve enough speed during starting process Cause Solution Starter battery voltage insufficient. Check battery. Damaged bearing(s) piston (seized). Repairs need to be carried out by Kubota-Service. (refer to Kubota motor-manual) Cooling water in combustion chamber. 1.

  • Page 105: Sooty, Black Exhaust

    Generator Faults Cause Solution Lack of oil pressure sensor tripped). Is indicated on the remote control Check oil-level and if necessary top up. panel. Check motor's oil-pressure and have repaired by Kubota-Service if necessary. 8.4.12 Sooty, black exhaust Cause Solution Generator is overloaded.

  • Page 106: Versions Of The Generator Power Terminal Box

    Generator Faults 8.5 Versions of the generator power terminal box Generator Power Terminal Box 120 V / 60 Hz Fig. 8.5-1: Generator power terminal box 120 V / 60 Hz Z1.2 In these terminal box there are the electrical connection points for the AC generator.
  • Page 107 Generator Faults Generator Power Terminal Box 240 V / 60 Hz (208 V / Fig. 8.5-3: Generator power terminal box 240 V / 60 Hz 60 Hz) In these terminal box there are the electrical connection points for the AC generator. Here is also the bridge for the protective grounding of the generator.

  • Page 108: Overloading The Generator

    Generator Faults Fig. 8.5-6: Wiring diagram DVS - 120 V + 240 V / 60 Hz 8.6 Overloading the generator Please ensure that the generator is not overloaded. This must be considered, especially with regards to multi power generators. In this case the extra load including the electrical performance can be considerably greater than the drive performance of the motor, which can eventually lead to a damaged motor.

  • Page 109: Monitoring The Generator Voltage

    „normally“. The Fischer Panda generators are aligned that they keep these default values during normal load. With high load or overload it can occur that the voltage drops on 190 V (95 V in the 60 Hz version) and partly still more deeply.

  • Page 110: Measuring The Ohm Resistance Of The Generator Windings

    Generator Faults (Note: The current arises from the rest magnetism of the rotor, which induces a voltage in the winding). 8.6.4 Measuring the Ohm Resistance of the Generator Windings If a short circuit could not be found by using a multi-meter, then the windings parts of the generator must be checked by means of an Ohmmeter that is suitable for low resistance values.

  • Page 111: Measuring The Inductive Resistance

    Generator Faults 8.6.6 Measuring the Inductive Resistance An Ohm measurement of a winding does not always give reliable information concerning the state of the winding. If there are resistance irregularities between the windings parts, this is a sure sign that the winding is defective. This means the opposite cannot be concluded.

  • Page 112: Engine Starting Problems

    Generator Faults 8.8 Engine Starting Problems 8.8.1 Electric Fuel Solenoid Valve The fuel solenoid valve is located in front of the injection pump. It opens automatically, if the „START“-button is pressed on remote control panel. If the generator is switched to „OFF“, the solenoid valve closes. It takes some seconds, before the generator stops.

  • Page 113: Lifting Solenoid For Motor Stop - Optional

    Generator Faults This period can be reduced by pushing the button on the front of the generator. The generator can be started by means of the remote control as long as the button is depressed. The switch/ button bypasses any faults allowing the generator to run.

  • Page 114: Check And Discharge The Capacitors

    Generator Faults the only handling error that can be made on board that can lead to fatal consequences for both generator and operator. 8.9 Check and discharge the capacitors NEVER check the capacitors whilst the generator motor Attention!: is running! Charged capacitors can be lethal. Do not contact the capacitors with bare fingers or non-insulated metallic objects! In order to test the capacitors, the terminal lead wires have to be disconnected using pliers...

  • Page 115: Troubleshooting Table

    Generator Faults Checking Fig. 8.9-3: Capacitor checking Switch the multimeter to capacitor measuring and connect the meter end probes to the capacitor terminals. Measure capacity of the capacitor. Check all capacitors in the electrical cabinet Test each capacitor by touching the multimeter (set on capacitor measuring) probes on the capacitor terminals: measure the capacity of the capacitors.
  • Page 116 Generator Faults Leere Seite / Intentionally blank Seite/Page 116 Kapitel/Chapter 8: Generator Faults 12.8.20...

  • Page 117: Tables

    Tables 9. Tables 9.1 Technical Data Fig. 9.1-1: Technical Data Panda 15mini Digital Type D902 Governor VCS 183 + Servo Automatic startbooster Cylinder Bore 72 mm Stroke 73,6 mm Stroke volume 898 cm³ Max. power (SAEJ1349) at 3600 rpm 17,5 kW Rated speed 3600 rpm Idle running speed ²...

  • Page 118: Cable Cross Section

    Tables Generato Rated current Generator Rated current Panda 14000 - 230 V / 50 Hz 48,0 A Panda 14000 - 400 V / 50 Hz 15,2 A Panda 14000 - 120 V / 60 Hz 112,7 A Other Generator typs on request! 9.3 Cable cross section Fig.

  • Page 119: Coolant Specifications

    Use a mixture of water and antifreeze. The antifreeze needs to be suitable for aluminium. The antifreeze concentration must be regularly checked in the interests of safety. Fischer Panda recommend to use the product: GLYSANTIN PROTECT PLUS/G 48 Engine coolant automotive industry Product description Product name GLYSANTIN ®...

  • Page 120: Coolant Mixture Ratio

    Tables 9.6.1 Coolant mixture ratio Water/antifreeze Temperature 70:30 -20 °C 65:35 -25 °C 60:40 -30 °C 55:45 -35 °C 50:50 -40 °C Seite/Page 120 - Kapitel/Chapter 9: Tables 12.8.20...
  • Page 121 User Manual Digital control system for generators FISCHER PANDA GENERATORS, INC. 351 S Andrews Avenue Pompano Beach, Florida 33069 Toll-free (800) 508-6494 - Phone (954) 462-2800 - Fax (954) 462-2801 E-Mail: service@fischerpanda.com -Web Site: www.fischerpanda.com Document release 002/ February 2020...
  • Page 122 Optical status indication ......................... 26 Control panel GP178 ........................... 28 User interface............................28 Interface description ..........................28 Operating the control system via control panel GP178 ................32 Powering up the control system ......................32 DS_VCS183 Page 1 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 123 Entering numerical values ........................37 Navigating through programing pages ....................37 Selecting / altering program data ....................... 38 Program panel ............................38 Program date/time ..........................38 Connection block KL188 and connection harness ..................40 DS_VCS183 Page 2 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 124 / temperature sensing devices as specified / detailed in this document. System components need to be wired as per Fischer Panda Inc. wiring diagram D00037 (see attachments to this document). Basically, the control system is made of the components listed below:...
  • Page 125 Wherever similar signals are used on different plugs such unambiguous matching may not be ensured. In these cases, it is however safe to plug in connectors in random order without compromising system functionality. DS_VCS183 Page 4 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 126 250g (Plugs not included) KL196: Ambient temperature: -10…+90°C 9…32V DC Supply voltage: Power consumption: Enclosure: IP00 Over-all dimensions: 85x55x20mm (Plugs not included) Mounting: 4 Bolts M4 Weight: (Plugs not included) DS_VCS183 Page 5 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 127 NTC temperature sensor B25/100 coefficient 3988 BN 2 CAN H Serial data link, CAN H =100kΩ and BN 3 Cyl. head Temperature signal cylinder head from NTC Element with R DS_VCS183 Page 6 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 128 CT186 and control panel GP178. Such communication runs on a serial data link as per ISO 1189 (CAN). Protocol details on this data connection are proprietary to Fischer Panda Inc. and not covered in this document. Any user interaction with the control system will be through the control panel which is then reporting back to the control system VCS183 via this data link.
  • Page 129 For this reason such emergency operation shall be restricted to an absolute minimum and the user is required to contact Fischer Panda Service immediately. Optical status Operational status of the current sensing device is indicated by 2 LEDs. For details see...
  • Page 130 “unacknowledged alarms pending” mode. This mode is described in more detail in this manual, see Unacknowledged alarms pending. DS_VCS183 Page 9 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 131 It points to a serious problem with potential catastrophic implications, leading to a total generator loss! Users are strongly advised to contact Fischer Panda for further advice if ever ending up in this situation! The control panel will report such status.
  • Page 132 0.2sec or 0.5sec, as appropriate for that input. In order for a certain warning or shutdown to be triggered the control system needs to read that input in critical status continuously for the programmed delay time. This is to avoid random shutdowns based on spurious fluctuations. DS_VCS183 Page 11 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 133 If cylinder head temperature sensor and coolant inlet temperature sensor are both enabled then at least one needs to report valid reading or the control system will detect a major fault since it has no way to read engine temperature. DS_VCS183 Page 12 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 134 AC readings. It will then behave as if there was no current sensing device connected, with the exception of tank level sensor and alternator bearing sensor still being evaluated. DS_VCS183 Page 13 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 135 Not detecting speed signal for a certain time is reported as “unexpected engine stop” but will also end up in operational mode “unacknowledged alarms pending”. DS_VCS183 Page 14 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 136 To leave this operational status the control panel needs to issue a stop command. This will cause all alarm messages –except those still active- to be cleared and the control system will now finally revert to regular stop mode. DS_VCS183 Page 15 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 137 Engine speed 1rpm Actuator voltage 10mV Actuator current 10mA Fuel pump current 10mA Water leak ADC output Operating time since last start 1min Total el. Energy since last start 0.1kWh DS_VCS183 Page 16 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 138 0.5% Engine speed 1rpm Actuator voltage 10mV Actuator current 10mA Pending warnings as per Table 6: Warning messages Pending warnings as per Table 4: Messages appearing as alarms or warnings DS_VCS183 Page 17 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 139 Low oil pressure alarms and low output voltage alarms obviously will not be active while the generator is not running. Some DS_VCS183 Page 18 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 140 Internal VCS hardware problem, generator will not start Problem while accessing SPI bus or reverse polarity protection MOSFET not engaging ST01 Fuel pump output is in short-circuit Will not reset other than through power cycle DS_VCS183 Page 19 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 141 Time slot for PID control algorithm Proportional constant Kp X0.01 Integral constant Ki X0.01 Derivative constant Kd X0.01 Maximum integral part Idling time Maximum cranking time AC voltage high, warning threshold 0.1V DS_VCS183 Page 20 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 142 Shutdown delay exhaust manifold temperature high 100ms Shutdown delay generator coil temperature high 100ms Delay oil pressure shut down 100ms Water leak trigger Tank alarm trigger 0.5% Tank level alarm delay DS_VCS183 Page 21 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 143 Delay shutdown max-current on gnd bk output 100ms Absolute max. exhaust temp. during warm-up 1°C Fuel priming time Absolute maximum cylinder head temperature threshold 1°C Service notifications enabled in VCS Actual time / date ** DS_VCS183 Page 22 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 144 Generator is warming up Cool down Generator is cooling down Waiting for AC- Generator start was detected based on oil pressure sensing. Waiting for AC voltage voltage to build up. DS_VCS183 Page 23 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 145 Selecting desired output Fischer Panda generators for commercial domestic applications will always provide two outputs of nominal 120V/60Hz each. Connection cables coming from these coils are labelled H1.1/H1.2 and H2.1/H2.2. Depending on the way these outputs are connected the power provided to the user is either 120V only or 120/240V.
  • Page 146 Connectors J1 and J2 serve as power supply and communication interface. Signals on these connectors are: • Pin 1: Power supply, positive o J1: Input from connection board KL188, fused 5A / F3 on KL188 DS_VCS183 Page 25 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 147 12kVA and higher; it is not required for generators with lower nominal output power. Fuel level sensor is supposed to be a linear resistive sensor with below specifications. It is not part of Fischer Panda scope of supply. Sensors connect to J8 as below: •...
  • Page 148 Tank sensor is enabled and reports open loop or short-circuit. o Temperature sensor for alternator bearing is enabled and reports open loop or short- circuit. • Green LED is steady on: No faults detected. DS_VCS183 Page 27 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 149 This input will process any optional remote inputs and report back system status. Some of the inputs are isolated via optic couplers; it should be noted that, if using power supply from connector J9, that galvanic isolation is cancelled out. DS_VCS183 Page 28 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 150 3 optically isolated inputs and the remote power-up. Status output and alarm output are mechanical contacts, rated max. 28V/max. 0.8mA resistive load. Contacts have internal self-resetting over-current-protection. DS_VCS183 Page 29 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 151 ANDed; the control system will report the fire boy message if any panel has this input in alarm condition. Input “Combat override”: This input is designed for military applications only and not covered in this manual. DS_VCS183 Page 30 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 152 The same resolution applies. DS_VCS183 Page 31 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 153 Across all these pages the bottom line is reserved to display pending messages or minor faults (regular display mode) or major faults (light text on dark background). While in basic display mode some minor DS_VCS183 Page 32 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.

  • Page 154: Acoustic Alarm

    Details about static / dynamic inputs and potential conflicts are covered in more detail under paragraph Digital inputs. DS_VCS183 Page 33 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.

  • Page 155: Advanced Selections / Data Menu

    1. Frequency as sensed by the CT board 2. Temperature CT186, main CPU control board 3. Temperature terminals of CT186 4. Temperature on VCS183 control board 5. Temperature inside control panel 6. Actuator voltage 7. Actuator current DS_VCS183 Page 34 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 156 16. HEX coded format of messages only (2 lines, “MISWL” and “MISWH”) 17. Calendar date as set in this panel 18. Time as set in this panel 19. Fischer Panda CAN node address 20. NMEA node address View system ID...
  • Page 157 40 being the most recent one recorded just prior to shut-down. Next 4 lines will show log data as per Table 3: Fast log data set scrolling upwards at a rate of approx. 0.8 sec. DS_VCS183 Page 36 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.

  • Page 158: Program Vcs

    Selecting “no” will return to first programming page and allows a review of all program data. Selecting yes will transfer newly programmed data into VCS183 and then power-cycle the control system. DS_VCS183 Page 37 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.

  • Page 159: Selecting / Altering Program Data

    (S4) or altered the same way as numerical values get altered (S2/S3). Once “Minutes” was updated the control panel will jump back to basic display page 1. Some restrictions /clarifications are mentioned below: DS_VCS183 Page 38 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 160 If a panel is connected to an NMEA2000 network then that panel’s date/time-settings will supersede any other panel. DS_VCS183 Page 39 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.

  • Page 161: Connection Block Kl188 And Connection Harness

    Figure 32: Kl188, detailed view F3, nominal capacity 5A: Power supply for CT186 and control panel(s) GP178 F3, nominal capacity 5A: Power supply for raw water motor valve DS_VCS183 Page 40 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.
  • Page 162 09/09/2019 Removed charger reference. Updated warnings and alarms 02/03/2020 Specified remote start/stop behaving with inputs configured static. Adapted for current firmware version. KL188 replaced by KL196 02/12/2020 Modified static/dynamic configuration paragraph DS_VCS183 Page 41 Rev. 06 www.fischerpanda.com ©Fischer Panda generators Inc.

Table of Contents
