CombiPrime V
8 Dimensions
8.1
CV/EN (1009) 5.3
Dimensions delivery flange
Figure 20: Dimensions delivery flange.
ab
32
40
50
65
80
100
125
150
ab
200
250
ISO 7005 PN 16
ad af
78 100
88 110
102 125
122 145
138 160
158 180
188 210
212 240
ISO 7005 PN 16
ad af
268 295
320 350
Dimensions
ah aj x al
140 4 x 18
150 4 x 18
165 4 x 18
185 4 x 18
200 8 x 18
220 8 x 18
250 8 x 18
285 8 x 23
ah aj x al
340 8 x 23
395 12 x 23
an
18
18
20
20
22
22
24
24
an
26
28
49
