The field "Max Info Frames" specifies the maximum number of information frames the node may send before it must pass the
token;
In the field "Device Istance" it is possible to assign a number to the BACnet node (used for the Device Istance).
The means of the fields for the "CANopen" section are:
In the field "ID Device" the ID of the CANopen side is defined;
In the field "Baud Rate" the data rate of the CANopen line is defined;
In the field "Set Operational State at
Operational State, else it starts in Pre-Operational;
In the field "Network Start at
command to set the Operational State of all the devices present in the network, after the time defined in the "Delay" field;
In the field "Delay (seconds)" the delay before sending the "Start" command for the CANopen is defined;
In the field "SDO Client TimeOut (1/10
is defined;
ADFweb.com S.r.l.
Start-Up" the state of the CANopen is defined. I.e. If it is checked the board starts in
Start-Up" the state of the CANopen network is defined. I.e. If it is checked the board sends a
ms)" the maximum time that the device attends for the answer from the Slave interrogated
