Specifications Techniques - Zephyr APEX DAP-M90AMBX Installation Instructions Manual

Specifications Techniques

Partie avant de la hotte
14-1/16''
Optional
Duct Cover
Partie latérale de la hotte
10-9/16''
Z1C-00MExx
(optional duct cover)
Optional
min. ducted - 50"
Duct Cover
max. - 60"
1''
6-3/4''
31-1/2''
35-3/8''
19-13/16''
Arrière de la hotte
Holes for
wall installation
Partie supérieure de la hotte
ELEC. KO
5-7/16''
- 37 -
10-13/16''
Optional
Duct Cover
15-3/16''
16''
21-9/16''
Holes for
wall installation
REMOTE BLOWER KO
5-7/16''
