USE, CARE, AND INSTALLATION GUIDE
Read all Instructions before Installing and operating this appliance
MODEL: ZPA-M90S
IMPORTANT SAFETY NOTICE
WARNING
Installation
The installation in this manual is intended for qualified installers, service technicians or persons
with similar qualified background. DO NOT attempt to install this appliance yourself. Injury
could result from installing the unit due to lack of appropriate electrical and technical
background.
All electrical wiring must be properly installed, insulated and grounded. Overly accumulated
grease in old duct work should be cleaned out or duct work should be replaced if necessary to
avoid the possibility of a grease fire. Check all joints on duct work to insure proper connection
and all joints should be properly taped.
Operations
Read all instructions in this manual before operating the appliance. Save these instructions for
future reference.
Always leave safety grills and filters in place. Without these components, operating blowers
could catch on to hair, fingers and loose clothing.
NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers.
NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch
fire. The risk of self combustion is higher when the oil has been used several times.
Cleaning
The saturation of greasy residue in the blower and filters may cause increased inflammability.
Keep unit clean and free of grease and residue build-up at all times to prevent possible fires.
Filters must be cleaned periodically and free from accumulation of cooking residue (see
cleaning instructions inside). Old and worn filters must be replaced immediately. Do not
operated blowers when filters are removed. Never disassemble parts to clean without proper
instructions. Disassembly is recommended to be performed by qualified personnel only. Call
our service center for removal instructions.
The manufacturer declines all responsibility in the event of failure to observe the
instructions given here for installation, maintenance and suitable use of the product.
The manufacturer further declines all responsibility for injury due to negligence and the
warranty of the unit automatically expires due to improper maintenance.
Advertisement
Table of Contents
Related Manuals for Zephyr ZPA-M90S
Summary of Contents for Zephyr ZPA-M90S
- Page 1 USE, CARE, AND INSTALLATION GUIDE Read all Instructions before Installing and operating this appliance MODEL: ZPA-M90S IMPORTANT SAFETY NOTICE WARNING Installation The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. DO NOT attempt to install this appliance yourself. Injury could result from installing the unit due to lack of appropriate electrical and technical background.
-
Page 2: Table Of Contents
CONTENTS INSTALLATION Mount heights & clearance Ducting Specifications Electrical Mounting the hood Duct cover EZ Anchors Ductless Conversion Carbon Filters FEATURES & CONTROLS Touch controls & features Advance display functions Filter change indicator Filter clean indicator MAINTENANCE Cleaning Lights replacement WARRANTY Coverage &... -
Page 3: Installation
INSTALLATION MOUNT HEIGHTS & CLEARANCE Minimum mount height between range top to hood bottom should be no less than 24". Maximum mount height should be no higher 35.43-53.15" than 32" 15.74" It is important to install the hood at the proper mounting height. -
Page 4: Ducting
INSTALLATION DUCTING WARNING: FIRE HAZARD NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. Use Metal ductwork only. Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct Tape. -
Page 5: Specifications
INSTALLATION SPECIFICATIONS 3/4" Elec. K.O. 8.66" 6.49" 3/4" 7/8" 6-3/4" 6" 19.7 - 37.4" 6-1/2" 35.43" 15.74" ELECTRICAL WARNING: All Electrical work must by performed by qualified electrician or person with similar technical know how and background. For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use extension cord or adapter plug with this appliance. -
Page 6: Mounting The Hood
INSTALLATION INSTALLATION Mounting the Range Hood 1. Measure from range top to hood bottom Duct Cover Bracket (24" min) Level and mark line 2. Plum and mark center line. 3. Mark mounting height line . (9-3/4" from line A) 9-3/4" 9-7/8"... -
Page 7: Ductless Conversion
1. Purchase ductless Charcoal Filters as follow: Hood Model: Part No. Filters in pkg. ZPA-M90S Z0F-C022 2. Remove metal filters on hood. Clip carbon filters onto each slot opening. 3. Re-install metal filters. 4. Turn on Filter Change Indicator on control panel (refer details pg. -
Page 8: Features & Controls
FEATURES & CONTROLS TOUCH CONTROLS & FEATURES Blower On/Off Display (Speed level, Delay Off Indicator, Filter Clean/ Change) Lights On/Off/ Hold to Dim Adjust 6 Speed Levels 15 Min Delay Off Blower On/Off By pressing , the blower is switched On and Off. When switched on, the blower starts up on speed level 3. -
Page 9: Filter Change Indicator
FEATURES & CONTROLS CONTROLS: FILTER CHANGE INDICATOR (Carbon Filters) Filter Change Reminder (Carbon, if fitted): When your hood is installed as a 'Purifying' (Ductless Recirculating) unit, it is fitted with a set of Carbon Filters to purify exhaust and fumes from cooking, and re-circulates the air within the home. - Page 10 FEATURES & CONTROLS CONTROLS: FILTER CLEAN INDICATOR (Metal Filters) Filter Clean Reminder (Standard Metal Filters fitted) Whether your hood is installed as an Exhaust or Purifying unit, a set of metal filters are fitted by the factory. These Metal Filters are intended to filter out residue from cooking. It need not be replaced on a regular basis but are required to be kept clean.
-
Page 11: Maintenance
Replacing Metal Filters Should filters wear out due to age and prolonged use, replace with following part number: Hood Model: Part No. Filters in pkg. ZPA-M90S Z0F-M032 Also replace damaged filter that has punctured or broken mesh, bent or broken frame. - Page 12 MAINTENANCE LIGHTS Replacing Light Bulbs CAUTION: Light bulb becomes extremely hot when turned on. DO NOT touch bulb until switched off and cooled. Touching hot bulbs could cause serious burns. Make sure all power is turned off and bulbs are not hot. Remove by turning bulb counter clockwise.
- Page 13 Damaged because of improper connection with equipment of other manufacturers. Repaired or modified by anyone other than Zephyr's Authorized Agents. What is Not Covered: Consumable parts such as light bulbs, filters, and fuses.
- Page 14 TO OBTAIN SERVICE UNDER WARRANTY or any Service Related Questions, please call: 1-888-880-8368 Have your product proof of purchase with date ready for warranty issues. Or write to: Zephyr Corporation Service and Warranty department 1551 Minnesota Street San Francisco, CA 94107...
