144 . Clarus 590 GC User's Guide
The following figure shows an installed PID.
Setting Up a P I D
To set up a PID, read the PID setup summary, then follow the steps.
PID Setup Sum m ary
To set up a PID:

Turn on the oven and the detector heaters.

•
• Adjust the make-up gas.
Adjust the make-up gas flow if using a capillary column at flows of ≤10 mL/min.
Turn on the UV lamp.
•
• Optimize the lamp intensity.
Turn on the Oven and the Detector Heaters
NOTE: A PID can only be installed in the Detector 2 position (rear).
1. Close the oven door. This turns on the oven heater.
2. From the System Status screen touch the PID icon .
