Introduction to BIGdsPIC6 Development System
™
The BIGdsPIC6
development system provides a development environment for programming and experimenting with dsPIC
microcontrollers from Microchip
your microcontroller using the on-board
2x16 LCD, real-time clock etc, are provided on the board and allow you to easily simulate the operation of the target device.
MikroElektronika
®
. The system includes an on-board programmer with mikroICD providing an interface between the
™
programmer. Numerous modules, such as 128x64 graphic LCD, alphanumeric
The dsPICFLASH program provides a complete list of all supported
microcontrollers. The latest version of this program with updated list of
supported microcontrollers can be downloaded from our website at
Development system: BIGdsPIC6
CD:
Cables:
Power Supply:
Power consumption:~40mA in idle state when all on-board modules are off
Dimension:
Weight:
BIGdsPIC6 Development System
Full-featured development
system for dsPIC
microcontroller based devices
USB 2.0 on-board programmer
Built-in debugger for testing
programs in real time at
hardware level
A possibility of reading
MMC/SD memory cards
Graphic LCD with backlight
product CD with relevant software
USB cable
installing USB drivers, electrical schematic of the system
over an AC/DC connector (7-23V AC or 9-32V DC); or
over a USB cable for programming (5V DC)
26,5 x 22cm (10,4 x 8,6inch)
462g (0.89lbs)
®
