Introduction
1 1

1.4 Frame Size Definitions

380–480 V AC
Active Filter current
A190
A250
A310
A400
A120
A120
A120
A210
A210
A210
A210
A330
Table 1.1 Active Filter Ratings
Frame designation
Table 1.2 Dimensions
Filters are available in IP21 and IP54.
1-2
Associated LHD power range
HO/NO (hp [kW])
175/225 [132/160]
225/275 [160/200]
275/350 [200/250]
350/425 [250/315]
425/500 [315/355]
500/550 [355/400]
550/600 [400/450]
450/500–630/700
Depth (in [mm])
D13 14.96 [380]
D14 14.96 [380]
E1 19.69 [500]
E9 19.69 [500]
F18 23.62 [600]
MG90Z122 - VLT
VLT Advanced Active Filter AAF006 D and E Frames Service Manual
Frame designation
Width (in [mm])
23.62 [600]
40.16 [1020]
23.62 [600]
47.24 [1200]
110.24 [2800]
®
is a registered Danfoss trademark
Weight of unit
Filter
D13 524.7 [238]
E1 945.8 [429]
E1 945.8 [429]
E1 998.7 [453]
D14 676.8 [307]
D14 676.8 [307]
D14 676.8 [307]
E9 1490 [676]
E9 1490 [676]
E9 1490 [676]
E9 1490 [676]
F18 4409 [2000]
Height (in [mm])
68.5 [1740]
68.5 [1740]
78.74 [2000]
78.74 [2000]
86.61 [2200]
lbs [kg]
