2.2 System Overview and General Specification

2.2.1 System Configuration for Stand-Alone Model
Figure 4 illustrates the system configuration of the Stand-Alone model with integrated user panel and buttons
to set the flow manually. The driver also contains a PLC interface for remote control by analog and digital
signals. Various accessories are available like a desktop power supply with relevant power cable and signal
cables to connect to the PLC.
Flow Out
4
5
Flow In
1
Figure 4: Standard system configuration for Stand-Alone model
2.2.2 System Configurations for EasyConnect Model
The EasyConnect model with relevant cable accessories is designed to realize various interface
configurations with minimal setup effort. The PLC interface allows remote control by analog/digital signals.
The Fieldbus interface enables remote control over a user panel, PC or other devices with Modbus protocol.
Flow Out
4
5
3
Flow In
Integrated Flow Control
EasyConnect Model
1
2b
PC Connection:
- System configuration
- Firmware update
- Monitoring
Figure 5: Standard system configuration for EasyConnect model
PL-4079-00, Rev00, DCO# 21-271
9a
IPS Cable Signal
3
Bayonet Socket
with Locking Pin
Integrated
Flow Control Driver
Stand-Alone Model
9a
IPS Cable Signal
Bayonet Socket
with Locking Pin
Power
Supply
PLC
Driver
Fieldbus
OUT
Fieldbus
IN
7
USB to RS485
Converter with Cable
User Manual for PuraLev
AC Input
AC Cable
6c
(International Adaptors)
Power Supply Power Supply
Connector Connector
Back-Side Display with
3 Button User Interface
IPS Cable Signal
PLC Connector
AC Input
AC Cable
6c (International Adaptors)
PLC Interface:
- Remote Control
- 24VDC Supply included
IPS Cable Signal
10
IPS Cable Signal
9a
IPS Cable Signal
9b
®
www.levitronix.com
Desktop
6b
AC/DC
Power
Supply
DC Output
Screw type connector for open-wires
connection included in cable package
9c
Option for Remote Control with
PLC Signals
6a
Desktop
DC Output
AC/DC
Power
Supply
Screw type connector for
open-wires connection
included in cable package.
14
User Panel
iF100SU
6
