UTILITY CLOSET CONNECTION LOCATIONS
IMPORTANT:
thermostat carefully to avoid interference. Hard-to-reach locations
will make installation and service difficult!
Use rigid duct for 90°
bends and tees
G
Installation Instructions
Plan and locate plenum, wall plug, drains and
Flex duct may be used
for transitions only
A
B
F
C
C
D
E
Platform
A Thermostat cable: 9
B Power cord: 60" long
C Case width and depth: 23
Outside wall
D Case height: 31"
E Condensate drains: 3/4" connector
• Primary Drain – Centerline of cutout is
approximately 5
and 8
• Secondary Drain – Centerline of cutout is
approximately 6
and 5
230/208 VAC
F Typical wall plug: 6"–12" above case
wall receptacle
or
G Room air sensor kit: 10' long
conduit for direct
connection
16
Reference Dimensions
' long
1 ⁄
2
"
1 ⁄
8
" from left case wall
1 ⁄
4
" from back case wall.
1 ⁄
2
" from left case wall
⁄
1
2
" from back case wall.
1 ⁄
4
