- Page 1 Instructions for the use - Installation advices VITROCERAMIC COOKING HOB ELBA QUALITY MADE IN ITALY Made in Italy...
-
Page 3: Declaration Of Ce Conformity
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 4: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 5 • Do not touch the appliance with wet or damp hands (or feet). • Do not use the appliance whilst in barefoot. • If you should decide not to use this appliance any longer (or decide to substitute another model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous parts be made...
- Page 6 • WARNING: Danger of fire: do not store items on the cooking surfaces. • Do not place or leave empty pans on the glass ceramic hob. • Do not allow heavy or sharp objects to drop on the glass ceramic hob.
-
Page 7: Features And Technical Data
FEATURES AND TECHNICAL DATA Fig. 1.1 M A D E I N I T A L Y 1. “Hi-light” cooking zone Ø 145 mm 1200 W 2. “Hi-light” cooking zone Ø 180 mm 1800 W 3. “Hi-light” triple cooking zone Ø... - Page 8 HOW TO USE THE TOUCH CONTROL Timer display: These indicators show • shows the number of minutes set/remaining which cooking zone(s) the • shows (cleared) if the timer is not set timer is set for: • if flashing: timer is selected and •...
-
Page 9: Using The Touch Controls
USING THE TOUCH CONTROLS • The cooking zone and timer displays also function as touch controls. To select a cooking zone or the timer, simply touch its display. Use the ball of your finger, not its tip. The controls respond to touch, so you don’t need to apply any pressure. -
Page 10: To Start Cooking
TO START COOKING Turn on the cooktop. Notes: (cleared) in the timer display means • that the timer is not set. • If you do not select a cooking zone within 20 seconds, the cooktop will automatically turn off. Turn on the cooktop. Select a heat setting ( 0 - 9 Note: setting... - Page 11 TO MODIFY THE HEAT SETTING DURING COOKING Select a cooking zone. Modify its heat setting.
- Page 12 WHEN YOU HAVE FINISHED USING A COOKING ZONE, YOU CAN TURN IT OFF, BUT CONTINUE TO USE OTHER COOKING ZONES: Select the cooking zone you want to turn off. Decrease its heat setting until the display shows . If the cooking zone surface is too hot to touch, will replace in the display.
- Page 13 USING THE TRIPLE (RIGHT) COOKING ZONE When you turn the triple (right) cooking zone on, only the inner section is on. Use the control to switch the outer and middle sections on or off. Only the inner cooking zone is on. The inner and middle cooking zones are All cooking zones (inner, middle and outer) are on.
-
Page 14: Locking The Controls
LOCKING THE CONTROLS • You can lock the controls to prevent unintended use (for example children accidentally turning cooking zones on). • When the controls are locked, all controls except the ON/OFF control are disabled. TO LOCK THE CONTROLS Make sure that the cooktop is turned on but no cooking zone is in use. - Page 15 USING THE AUTO HEAT-REDUCE FEATURE Cooking zones set for this feature will: • first quickly heat up food or liquid at the highest setting • then automatically reduce the heat to a preset lower setting to cook the food through. TO SET A COOKING ZONE FOR AUTO HEATREDUCE Select a cooking zone.
- Page 16 WHEN AUTO HEAT-REDUCE IS SET Initially, while the cooking zone is at the highest setting, will flash alternately with your selected lower setting. Then, when the period of highest setting is over (eg after 5 minutes), will stop flashing and the cooking zone will automatically reduce the heat to your preset lower setting.
- Page 17 USING THE GENTLE HEAT FEATURE This heat setting between provides continuous gentle heat and is ideal for: • delicate cooking tasks such as melting chocolate • warming plates • keeping cooked food warm. If reheating cooked food from cold, always bring it to the boil on a higher setting before changing to the GentleHeat setting.
-
Page 18: Using The Timer
USING THE TIMER You can set the timer to automatically turn one or more cooking zones off when the set time is up. Important! Never leave the cooktop unattended when in use, even if you have set the timer to automatically turn a cooking zone off. - Page 19 Set the right-hand digit using the setting selector. The display will then indicate for you to set the left-hand digit. Set the left-hand digit using the setting selector. The timer is now set and begins counting down.
- Page 20 WHEN THE SET TIME IS UP • The corresponding indicator in the timer display will flash, the timer will beep, and the cooking zone will automatically turn off (its display showing if the surface is hot). • Touch any control to stop the beeping. Notes on using the timer •...
-
Page 21: Cooking Hints
COOKING HINTS: Do not scratch the cooktop with • To reduce the cooking time, you cutting or sharp objects. can set the fast cooking function (cf. Do not use the glass ceramic surface section “USING THE AUTO HEAT- as a work surface. REDUCE FEATURE”... - Page 22 ADVICE FOR SAFE USE OF THE COOKTOP • Before switching on make sure that DISTORTED you have the correct knob for the PANBASE hotplate chosen. It is advisable to WRONG put the pan on the hotplate before switching on and to take it away after switching off.
-
Page 23: Heat Settings
HEAT SETTINGS Heat setting... -
Page 24: Troubleshooting Chart
TROUBLESHOOTING CHART Problem Possible causes What to do Make sure the cooktop is connected to the power supply and that it is switched on at the wall. Check whether there is a The cooktop cannot be No power. power outage in your home turned on. - Page 25 Problem Possible causes What to do The cooktop turns itself cookop electronics off unexpectedly and the have overheated and the Let the cooktop cool down cooking zone displays cooktop turns itself off as a before using it again. read out alternating safety measure.
-
Page 26: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE • Before you begin cleaning, you must ensure that the appliance is switched off and disconnected from the electrical power supply. • Under no circumstances should any external covers be removed for servicing or maintenance except by suitable qualified personnel. •... - Page 27 ADVICE for the INSTALLER...
- Page 28 IMPORTANT : • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have.
-
Page 29: Installation
INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 4.1a has to be made, bearing in mind the following: • A 20mm ventilation gap must be provided between the bottom of the appliance and any cabinetry, draw unit, thermal protection barrier or oven. - Page 30 Fig. 4.1a The thermal protection barrier must • removable with the use of a tool for installation and service; • heat-resistant; • made from thermal conductivity material. Cooktop installed Fig. 4.1b Fig. 4.1c Measures (mm) Description (minimum) (minimum)
-
Page 31: Fastening The Cooktop
FASTENING THE COOKTOP Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 30 to 40 mm thick. The kit includes four “A” brackets and four “B” self-threading screws (fig. 4.2). •... -
Page 32: Electrical Section
ELECTRICAL SECTION IMPORTANT: The appliance must be installed by a qualified technician according with the current local regulations and in compliance with the manufacturer instructions. Incorrect installation might cause harm and damage to people, animals or objects, for which the manufacturer accepts no responsibility. Connection to a good earth wiring system is absolutely essential. -
Page 33: Connection Of The Power Supply Cable
CONNECTION OF THE POWER SUPPLY CABLE Important! This cooktop must be connected to the electricity supply only by an authorised person. To connect the feeder cable to the hob it is necessary to carry out the following operations: • Unhook the terminal board cover “A” by inserting a screwdriver into the two hooks “B” (fig. - Page 34 Fig. 5.1 Fig. 5.2 220 - 240 V~ 380 - 415 V 2N~ 380 - 415 V 3N~ N (L...
- Page 36 The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacturer commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances. www.elba-cookers.it Made in Italy Cod. 1105300 - ß1...
