Zippity Urban Escape Vinyl Fence Quick Start Manual

WARNING!

If your yard has a severe slope or elevation change greater than approximately
7" to 8" over one panel of fence, you will not be able to install this fence.
Your post will not be long enough to accommodate.

How to Accommodate Sloping Ground?

This fence can be installed in a Racking Fashion, or a Stair Step Fashion. See illustrations below.

RACKING FASHION

Dig the lowest board into the
higher side of elevation.
Use excavated dirt to fill in
lower elevations as necessary.

STAIR STEP FASHION

Dig the lowest board into the
higher side of elevation.
Use excavated dirt to fill in
lower elevations as necessary.

Tips

• Use a fine tooth metal or wood blade for trimming down PVC components.
• For easier spacing of posts, you can optionally use a piece of lumber trimmed down to 69 inches.
4

PRODUCT OVERVIEW

The boards need to be trimmed.
All Posts Include One 46 Inch
Long Internal Steel Sti ener
3 in.
The portion of the vinyl post that includes
the steel sti ener MUST be installed
into the concrete footing as illustrated.
Discover the Bene ts of Zippity Vinyl Fence
•
•
•
•
•
Urban Escape Vinyl Fence w/Post
This fence can be easily trimmed down in width and
height to accommodate shorter applications.
Internal Steel Sti ener
72 3/4 in.
46 in.
(Pre-Installed)
3 in.
2 in.
32 in.
10 in Dia x 36 in Deep Concrete (or below your frost line)
Made of durable, low-maintenance white vinyl
Post design offers architectural character and flexibility when installing fence
Post design also offers 4-way universal directional capabilities (you do not need to order end, line, corner or specialized gate posts)
Tongue and groove horizontal boards offer symmetrical appearance; same look on both sides of the fence
Limited Lifetime Warranty
Please visit www.zippity-outdoor.com or call us at
We are eager to help you succeed in your project. Thanks for choosing Zippity, and all the best with your project.
(6' High x 6' Wide)
You will need to purchase at least one extra
post to complete your fence project.
70 in.
Leave approximately a1/8 inch gap
between end of board and back of
post groove to allow for thermal
expansion and contraction of boards.
69 in.
75
Wind Rated
72 in.
75 in.
1-877-234-6196
for answers to your other questions.
Km/H
1
