Handset; Buttons - ASCOM Myco 3 Quick Reference Manual

Handset

Top multifunction
button
Microphone
Front Multifunction
camera

buttons

Power
button
Volume
button
Main
display
Back
button Home button
Microphone
Micro USB charging port
ascom
1
Multi-color
LED
Ascom IR location
Exchangeable
Back camera
color pad for
clip
Overview Battery
button cover lock
3.5 mm
Headset jack
© 2021 Ascom. All rights reserved. TD 93301EN / March 2021 / Ver. C
Buttons
The handset is equipped with Back, Home, Overview, Power, Volume, and three
Multifunction buttons.
Multifunction buttons
1
• Depending on the configuration, this button can
be used for different purposes. For example, you
can scan a barcode or start an app.
Power Button
2
• Press and hold to turn the handset on / off or
Barcode
restart it.
scanner
• Press to lock and put the handset into sleep
mode.
• Press to wake up the screen from sleep mode.
Clip
Volume Button
3
• Press up (+) to increase or press down (-) to
decrease the volume level.
Battery
• Press and hold down (-) to mute all the sounds.
pack
Press down (-) again to put the handset in silent
mode.
Back Button
4
• Press to navigate backwards, to the previous
screen.
Home Button
5
• Press to wake the screen from sleep mode.
• In unlocked mode, press to navigate to the
Home screen from any app.
Overview Button
6
• In unlocked mode, press to see a list of all
active apps.
ascom
1
2
3
5
4
© 2021 Ascom. All rights reserved. TD 93301EN / March 2021 / Ver. C
1
6
2
