Battery Replacement

Slide the battery cover lock to the right to release the battery.
1
While pressing and holding the upper part of the clip, lift the battery and pull it
2
out.
1
Press the clip once agin. Insert a fully charged or new battery and press it in.
3
Slightly press on the battery and slide the battery cover lock to the left to lock
4
the battery.
The battery has been properly inserted if none of the battery parts is
5
detached.

Charging Methods

The handset has a rechargeable battery that can be charged separately from the
handset. To charge it, use the Battery Charging Rack or the Desktop Charger.
If you want to charge the handset, do it either with a Handset Charging Rack,
Desktop Charger or a Micro USB cable.
With the Desktop Charger you can charge the handset together with one extra
battery.
ascom
9
2
© 2021 Ascom. All rights reserved. TD 93301EN / March 2021 / Ver. C

Desktop Charger

Use the Desktop Charger to charge only the handset or the handset together with
one extra battery.
Handset Charging
Place the handset in the charging slot for handsets. Push the handset into
1
the charger to fully insert it. If the handset is correctly inserted, the charging
screen appears showing the battery charge level and the owner ID.
When the green check mark icon appears on the screen and the LED turns
2
green, the battery is fully charged.
Handset Disconnection
Tilt the handset towards you and then lift the handset upwards to remove it from
the charger.
