Battery Charging Rack

Battery Charging
Remove the battery pack from the handset and place it in the charging slot.
1
Secure the battery by moving the battery cover lock to the left.
If the battery has been correctly inserted, the LED turns amber to show that
the battery is charging.
When the LED turns green, the battery is fully charged.
2
Battery Disconnection
Unlock the battery by moving the battery cover lock to the right.
1
Lift the battery and pull it out from the charger.
2
ascom
13
© 2021 Ascom. All rights reserved. TD 93301EN / March 2021 / Ver. C

Micro USB Cable

Open the charging port at the bottom of the handset.
1
Attach the Micro USB cable to the charging port and connect USB Power
2
supply to a power outlet.
When the LED turns green, the battery is fully charged.
3
Close the charging port to prevent liquid and dust damage.
4
