1 Button to unlock battery for removal
2 Monitor connector
3 Locking lever
4 Battery with "Test" button and charge level indication
5 button with indicator to enable and disable the synchronized operating mode (when the
Sync.
synchronized mode is enabled, the indicator is illuminated and goes off with each sync pulse)
6 Charging Status indicator
solid yellow: battery charging
solid green: battery charged
blinking yellow: charging error (replace battery)
flashing green: battery conditioning program active
7 button to turn the defibrillator on and off (indicator is illuminated when the device is
On/Off
turned on)
8 buttons to select the defibrillation energy
Energy Select
9 button to initiate defibrillator charging
Charge
10 buttons to release the shock when adhesive or internal electrodes are connected (both
Shock
buttons must be pressed simultaneously);
the indicator lights up when the defibrillator is charged
11 button to select the pacer operating mode (fixed rate, demand)
Pacer Mode
12 button to suspend delivery of pacer pulses (without changing the pacer settings)
Pacer Pause
13 button with indicator to turn the pacemaker on and off (when the pacemaker is
Pacer On/Off
enabled, the indicator is illuminated and goes off with each delivered pacer pulse)
14 button to change the pacer output current
Output (mA)
15 Rate button to change the pacer rate
(ppm)
16 Contacts for test discharge (possible only with adapter lead for adhesive defibrillation pads)
17 Connector for exchange of the defibrillation electrodes (switch off the device before exchanging
the electrodes!)
