• Please read and understand the instructions prior to assembly.
Incorrect installation of this product could possibly result in
personal injury or physical damage.
• WallBeds Australia recommends two people to safely assemble
and install the wall bed - It is not recommended you try to install
this bed on your own.
• The wall bed MUST be securely fastened to the wall prior to use.
Failure to do so will cause the bed to tip over & may cause
damage to the cabinet or serious personal injury.
• All additional cabinetry must be securely fasten to the Wall Bed
cabinet.
• Whilst these products are DIY it is recommended the wall bed be
installed by a qualified trades person if you are not comfortable
with the installation of this product.
©2020 WallBeds Australia V4
Important Safety Advice Sheet
PLEASE READ BEFORE YOU BEGIN:
WallBeds Australia is not responsible for any damages
or injuries incurred by incorrect installation of this
product.
1

Advertisement

loading

Related Manuals for Wallbeds Australia AB-4

Summary of Contents for Wallbeds Australia AB-4

  • Page 1 Incorrect installation of this product could possibly result in personal injury or physical damage. • WallBeds Australia recommends two people to safely assemble and install the wall bed - It is not recommended you try to install this bed on your own.
  • Page 2 Panel Stickers/Labels –Do not remove any cabinet stickers from the panels until the units have been built, as these will assist with assembly. Most of the stickers are placed on the “back” or underside of the cabinet and will not be seen once assembled. AB-4 Drawer Unit Panels End Left Back...
  • Page 3 AB-4 Drawer Unit Hardware Small Handle Drawer Clip Drawer Runners & Metal Drawer Sides 28mm Wood Screw Cam Pin Handle Fixing Screw Cam Lock Done Head Screw Euro Screw Step 1 – Inserting Drawer Unit Hardware Cam Locks – Insert all Cam Locks into the following panels as described by the cabinet part located on the cabinet sticker.
  • Page 4 Insert these into the drawer front, ensuring the up & down arrows on the drawer clips are facing the outside edge of the drawer panel. Fix these into the drawer front by tapping them in gently with a hammer - Refer to image 5 page 9 ©2020 WallBeds Australia V4...
  • Page 5 Step 2 Ab-4 Drawer Unit Assembly Start the cabinet assembly by using either one of the End Panels. Back Panel - With the cam locks are facing away from the inside. Place the cabinet back panel onto the side panel. Match up the cam locks with the cam pins. Tighten the cam locks and cam pins together by using a Phillips head hand screwdriver.
  • Page 6 AB-4 Bookcase Instructions Note: If you have two of the same cabinet each cabinet will have a different cabinet number. Prior to assembly, separate and group all matching panels panel numbers. Panel Stickers/Labels –Do not remove any cabinet stickers from the panels until the units have been built, as these will assist with assembly.
  • Page 7 AB-4 Bookcase Hardware Parts Cam Lock Cam Pin Shelf Pin 28mm Wood Screw Step 1 – Inserting Hardware Cam Locks – Insert all Cam Locks into the following panels as described by the cabinet part located on the cabinet sticker.

  • Page 8: Important Safety Information

    Avoid using a razor blade as you may damage the cabinetry. IMPORTANT SAFETY INFORMATION All WallBeds Australia Bookcases and Cabinets must be securely attached to the WallBed before use. Ensure that children DO NOT climb or hang on any part of the Bookcase or Cabinet.
  • Page 9 Image 2 Image 1 Image 3 Image 4 Image 5 ©2020 WallBeds Australia V4...
  • Page 10 Image 7 Image 6 Image 9 Image 8 ©2020 WallBeds Australia V4...
  • Page 11 • Insert a small tip screw driver into the hole in the drawer clip as circled above. • Apply a small amount of pressure to release the plastic clip inside. • Lightly pull on the drawer front whilst pressing on the plastic clip. ©2020 WallBeds Australia V4...
  • Page 12 These images may not represent each individual product. IMPORTANT SAFETY INFORMATION All WallBeds Australia Bookcases and Cabinets must be securely attached to the WallBed before use. Ensure that children DO NOT climb or hang on any part of the Bookcase or Cabinet.
