- Page 1 Assembly Instructions Alpha WallBed Studio Desk ** LIFETIME WARRANTY ** Designed to Exceed International ISO 9002 Standards for Residential Specifications - Patent Pending - Issue:041414 Let’s build a Wallbed together! ©2020 WallBeds Australia V1.7...
- Page 2 DESK PACKER BETWEEN PIVIOT BRACKET & THE INSIDE OF THE WALLBED END PANEL (10pc) #8x40mm Wood Screws (30pcs) 19mm Self tapping Screw Pivot Brackets attach to wall bed End/Side Panels. The Desk/Table panels to the Upper Brackets ©2020 WallBeds Australia V1.7...
- Page 3 R/H Side When You Are Facing The Wallbed. L/H Side When You Are Facing The Wallbed. Pivot Bracket (Left and Right) Legs to Pivot Brackets (2pc) M6x40mm Bolt (4pcs) Black Steel Washer Ø7.0xØ16.0mm (2pcs) M6 Nylock Nut ©2020 WallBeds Australia V1.7...
- Page 4 • Attach the Desk Packers to the wall bed End Panels. Ensuring the head of the wood screw is flush or lower than the surface of the Desk Packer. Once fully assembled these leg packers will square up the studio desk legs with the cabinetry. ©2020 WallBeds Australia V1.7...
- Page 5 Drawing #1: Upper Desk Top and Back Panel Bracket Desk Back Panel Desk Top Panel Drawing #2: Hinges to Desk Back Panel The short Hinge leaf attaches to the Back, the long Hinge leaf will attach to the Bed Face Panel. Back Back Panel ©2020 WallBeds Australia V1.7...
- Page 6 Place the previously assembled Desk on the floor where it will be located when it is in use. Hand tighten the Bolts as the Legs needs to be detached later to mount the Desk to the Bed Face. (Drawing #4). Drawing #4: Desk on floor (Side View) Cabinet Pivot Desk Top Bracket ©2020 WallBeds Australia V1.7...
- Page 7 Leaf 38mm Clip Shelf Hinge Desk Back Clip Hinge Clip Shelf Hinge Clip Face STEP 5: Test Open WallBed to operate the Desk slowly. Double check the levels. Make sure that all End Caps are installed. ©2020 WallBeds Australia V1.7...
