Owner's Manual
Owner's Manual
Media Director V2 Lectern
Standard Media Director V2
55260
w/ TouchLink™ Cubby Panel 350CV cut-out in work surface
LH cut-out
RH cut-out
(no overbridge)
55345
55346
55294
w/ blank overbridge (OB-3)
w/ MediaLink™ MLC 226 IP AAP cut-out in overbridge (ES-3)
55234
w/ TouchLink™ 700MV cut-out in overbridge
55347
Media Director V2 Lectern
Media Director V2 Lectern
55260TW
55260TW
Media Director V2 Lectern w/ MediaLink™
MLC 226 IP AAP cut-out in overbridge &
arched toe kick (ES-3)
55234TK
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for choosing Spectrum products!
Spectrum Industries, Inc.
Chippewa Falls, WI 54729, USA
Media Director V2 Lectern w/ toe kick
Media Director V2 Lectern w/ toe kick
55260TK
55260TK
Media Director V2 Lectern w/ toe
kick & blank overbridge (OB-3)
55294TK
Before using this product, read this manual and follow all safety and
operating instructions.
Before you begin, please make sure all parts and proper quantities are
included. Any parts damaged during shipment must be reported within 15
days of receipt. To report information regarding damages or if you have any
questions, please call 1-800-235-1262.
Media Director V2 Lectern w/ RH
Media Director V2 Lectern w/ RH
TouchLink™ Cubby Panel 350CV cut-
TouchLink™ Cubby Panel 350CV cut-
out in work surface
out in work surface
55346TW
Media Director V2 Lectern w/ TouchLink™
700MV cut-out in overbridge
55347TW
CAUTION:
IMPORTANT:
0103148XR6 Page 1 of 9
0103148XR6 Page 1 of 9
