Owner's Manual
LINK Lectern with Overbridge Control Console
55283
36"H LINK Lectern with overbridge
55284
42"H LINK Lectern with overbridge
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
™
Spectrum product page:
http://bit.ly/LINK-OCC
0116143R3 Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Spectrum Industries 55283
Summary of Contents for Spectrum Industries 55283
- Page 1 Thank you for purchasing Spectrum products! Spectrum Industries, Inc 925 First Avenue, Chippewa Falls, WI 54729 USA 800 235 1262 715 723 6750 www.spectrumfurniture.com...
- Page 2 If servicing is necessary, please contact Spectrum Industries for assistance. Warning - Relocating audio and/or video equipment to furniture not specifi cally designed to support audio and/or video equipment may result in death or serious injury due to the furnishing collapsing or over turning onto a child.
- Page 3 Assembly / Setup Overbridge insert panel Note: The insert panel shown (shaded) is not included with the lectern or over- bridge. This option needs to be ordered separately to complete the overbridge. Drill Drill bit Jigsaw or Router 1. To remove the overbridge insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a 4mm hex wrench and lift out the panel.
- Page 4 LINK Lectern overbridge panel blank (flat view) 2” grommet 2” grommet max cutout area Figure 2 ™ Note: The Overbridge Control Console has been designed for many of the cur- rently available controllers on the market, however, modified cutouts should be re- viewed by Spectrum to ensure clearance of brackets, keyboard slides, or other objects under the worksurface.
- Page 5 Floor Anchoring (Toe Kick models only) 4mm Hex wrench 1. If your LINK is equipped with a toe kick, and you wish to attach it to the floor, the toe kick will need to be detached from the lectern. To detach, remove the (4) 1/4-20 x 40mm JC bolts (one on each corner from inside the lectern) with a 4mm hex wrench.
- Page 6 Wheel operation Brake lever 1. To lock the wheel rotation, press the brake lever. Figure 8. 2. To resume operation, lift up on brake lever. Moving and parking the lectern Figure 8 • Before moving, unplug and secure all power cords. •...
- Page 7 Accessories Note: Flip-up document shelf and steel handle are interchangeable and can be mounted on either side. Steel Handle - 55132 Flip-up Shelf - 55140 Overbridge Insert Panel 27.5”W 22.75”W x 26.25”D 96504 - blank panel (mounts on left or right side) 96504mod - panel with cutout(s) includes 2”...
- Page 8 • 10 Years • Cart Chassis • Lectern Chassis DESIGNED AND MANUFACTURED IN CHIPPEWA FALLS WISCONSIN.USA 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM © 2015 Spectrum Industries Inc., All rights reserved. 0116143R3 Page 8 of 8...
