Owner's Manual
Masters Interactive Lectern
55250
with CC600 worksurface cutout
55251
without worksurface cutout
55352
with Overbridge Control Console
Masters Lectern
with CC600 cutout
55250TW
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
™
™
Masters Lectern
without worksurface cutout
55251TW
Masters Lectern
with Overbridge Control Console
55352TW
shown with optional insert panel (shaded)
0115348R3 Page 1 of 9
™
