Owner's Manual
Doctorate Lectern
55245
w/ CC800 worksurface cutout
55244
without worksurface cutout
55353
w/ Overbridge Control Console
Doctorate Lectern
w/ CC800 cutout
55245TW
CAUTION:
Before using this product, read this manual and follow
all safety and operating instructions.
Before you begin, please make sure all parts and
proper quantities are included. Any parts damaged
during shipment must be reported within 15 days of
receipt. To report information regarding damages or if
you have any questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
Chippewa Falls, WI 54729, USA
™
Doctorate Lectern
without worksurface cutout
55244TW
Doctorate Lectern
w/ Overbridge Control Console
55353TW
shown with optional insert panel (shaded)
0107155R1 Page 1 of 10
™
