Spectrum Industries Academic Lectern 55421 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual
Academic Lectern
55420
Academic Lectern KD (Knocked Down)
55421
Academic Lectern (Pre-assembled)
Academic Lectern
Before using this product, read this manual and follow all safety and
operating instructions.
IMPORTANT:
Before you begin, please make sure all parts and proper quantities are
included. Any parts damaged during shipment must be reported within 15
days of receipt. To report information regarding damages or if you have any
questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for choosing Spectrum products!
Spectrum Industries, Inc.
Chippewa Falls, WI 54729, USA
55420
CAUTION:
55420TK
Academic Lectern w/ toe kick
0110042 Page 1 of 10
