States
Define the different machine conditions or states that the Vigilant unit
will consider. They allow the user to define different Storage
strategies and apply different alarm limits for the measurements
depending on these machine states.
Storage
These elements define what measurements will the Vigilant store in the
database. They are defined by selecting an event and setting a condition.
See
Storage Strategies
Processing
These objects set the signal processing that will be applied to the inputs of
Modes
the Vigilant (filtering, enveloping, rectification, etc.), and defines the
properties of the spectrum and waveform that will be measured
(sampling frequency, window type, resolution, averages, number of
samples, etc.). For each point the system can measure several Processing
modes.
Parameters
These are scalar measurements that are calculated from the time signal
configured at the Processing Mode and using different mathematical
algorithms (overall values, spectral bands, crest factor, kurtosis, etc.).
The machines defined on the unit will be shown on the configuration tree, below the "Machines"
label. Alternatively clicking on Machines on the configuration tree the interface will show the list of
machines:
From this list the machines can be deleted or copied by using the buttons on the right of each item.
Clicking on one of the machines of the list, or on the tree, the interface will show its configuration.
Click on the "new" button to create a new machine from scratch.
for more information
(Optional software
Vigilant User Manual
features).
90/210
