Field Description
Name Defines the name to the Widget. It will be shown at its upper bar.
Machine Selects from the pull-down list the machine mimic to be shown.
Show first Show value of the Main parameter below the label of the points.
parameter value
Image size Sets the way the image fits on the space of the Widget: Normal will
show the image at its normal resolution, Double increases 2 times the
size of the image, Cover all fits the image file to the total space available
on the Widget.
13.6.2

Display

The following picture shows the Mimic Widget and its components.
