Access to trends chart

By clicking on the measurement value, the interface will present a window with the trend of the
parameter. The graph will have all the options as the trend Widget. This window can be closed by
selecting the corresponding button of the window or by pressing the ESC key.

13.6 Mimic

This Widget displays the image associated to the machine, along with its measuring points.
13.6.1

Configuration

The following picture shows its configuration settings. Once the Widget is selected click on the
shortcut key "c" or the button in order to show its configuration form.
