USER MANUAL
Version 2 – August 2020
© SDT International. All rights reserved. Specifications are subject to change without notice.
SDT International sa-nv • Bd de l'Humanité 415 • B-1190 Brussels (Belgium) • Tel: +32(0)2 332 32 25 • email: info@sdtultrasound.com
SDT North America • 7677 County Road 2, Cobourg, ON • Phone: 1-800-667-5325 | 1-905-377-1313 • email: hearmore@sdtultrasound.com
www.sdtultrasound.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Online4US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SDT Online4US

Summary of Contents for SDT Online4US

  • Page 1 © SDT International. All rights reserved. Specifications are subject to change without notice. SDT International sa-nv • Bd de l’Humanité 415 • B-1190 Brussels (Belgium) • Tel: +32(0)2 332 32 25 • email: info@sdtultrasound.com SDT North America • 7677 County Road 2, Cobourg, ON • Phone: 1-800-667-5325 | 1-905-377-1313 • email: hearmore@sdtultrasound.com...

  • Page 2: Table Of Contents

    3. Home screen overview ......................44 3.1. Home Screen ........................45 4. Info screen overview ......................46 4.1. Info screen ........................... 47 4.2. Memory management screen overview ................48 4.3. Debug screen ........................54 5. Recommended steps throughout initial Online4US-ACM settings .......... 55 2/75...
  • Page 3 Online4US User Manual Part 3: Communication 1. Communication ........................56 2. Specifications ........................56 2.1. RS-232 38400-8N1 ....................... 56 2.2. RS-485 38400-8E1 ....................... 56 2.3. Ethernet 10/100T ........................ 56 3. Protocol ..........................57 3.1. Measures ..........................57 3.2. Commands ........................... 58 4.

  • Page 4: Part 1: Hardware

    The CPU/CUM has a RS485, a RS232 and an ethernet connectors for alarms and data distribution to a PLC or a SCADA system (Supervisory Control and Data Acquisition). It has an on/off switch that cuts the power of the Online4US but does not cut the power of the transformer.

  • Page 5: Bus Expander And Termination Module

    The module is able to receive: • Structure borne US sensor; • Airborne US sensor. The sensors are specific to Online4US. ❶: First channel sensor connector cable. Wiring (from left-to-right) GND (Ground), +5V (amplifier power supply), 0V (amplifier power ①...

  • Page 6: Vib Sensor Module

    Pre-amplified airborne US sensors (integrated cable); • Pre-amplified structure borne US sensors (separate cable). US sensor module has outputs for connecting an SDT handheld device and/or an analyzer. 1.3.1. Airborne US sensor Airborne sensor is designed in two parts: •...
  • Page 7 SDT handheld device VIB sensor module can host one or two ICP accelerometers having 100 mV/g output. VIB sensor module has outputs for connecting an SDT handheld device and/or an analyzer. 1.4.1. Accelerometer SDT proposes an ICP 100 mV/g accelerometer with a M6 thread but Online4US is compatible with any 100 mV/g ICP accelerometers.

  • Page 8: Digital Output Module

    ② ③ Figure 7: Digital output module As Online4US manages 8 groups and for each group two digital outputs are used (one for the warning status and one for the danger status): • One DOM is needed when using up to 4 groups;...

  • Page 9: Digital Input Module

    • Nothing (or 0 or Off). 1.5.1. Powering digital outputs Note 1: Online4US DOM is working on sourcing mode, each digital output provides the voltage source to the load and all digital outputs are bridged to the +VDC. Online4US DOM...

  • Page 10: Analog Input Module

    All (or 1 or On); • Nothing (or 0 or Off). 1.6.1. Powering digital inputs Note 1: Online4US DIM is working on sinking mode: each digital input is (internally) bridged to the ground needed in the circuit. Online4US DIM Input 1...
  • Page 11 4. Analog input 7; 5. Analog input 8; 6. Isolated 12VDC (same as connector As Online4US manages 8 groups, the AIM (Analog Input Module) has 8 independent inputs. The assignation is as following: • Analog input 1 is assigned to group 1;...

  • Page 12: Main Unit

    Online4US User Manual 1.8. Main unit Figure 12: Main enclosure with the display, inner and transparent doors Figure 13: Mounting plate of the main unit with power supply, CPU/CUM, din rails, bus termination module, terminal blocks The main unit contains max one CPU/CUM, one power supply, 9 additional modules and 1 bus expander and termination module.

  • Page 13: Extension Unit

    Online4US User Manual Figure 14: The maximum number of modules is achieved in the main unit The main unit delivery includes: • 1 enclosure; • 1 inner door; • 1 mounting plate; • 1 transparent door; • 1 power supply;...

  • Page 14: Hardware Rules

    Online4US User Manual The expansion unit delivery includes: • 1 enclosure; • 1 solid door; • 2 bus termination modules; • 3 din rails; • 2 inter bus connection cables; • 1 inter enclosure connection cable; • Terminal block; •...

  • Page 15: Din Rail Bus

    Online4US User Manual  ❶: The first module is the bus expander and termination module ❷: The last module is the bus expander and termination module  Figure 17: Bus termination module position for the expansion unit A din rail can accommodate up to 4 modules.

  • Page 16: Bus Inter Rail Connection Cable & Bus Inter Enclosure Connection Cable

    Figure 21: The inter enclosure cable connects the expansion unit to the main unit 1.13. Adding a module Important notice: prior to module installation, the SDT Online4US must be first powered off using the CPU/CUM sliding switch (refer to CPU/CUM details for more information).
  • Page 17 6. Clip the din rail bus of the bus termination module; 7. Firmly plug it to its left neighbor. 1.13.1. Plugging a din rail bus Online4US should be switched off. ❶: Clip the din rail bus on the din rail until it clicks. Ensure the locking tabs are all in...

  • Page 18: Removing A Module

    Online4US User Manual 1.13.3. Connecting the expansion unit to the main unit Online4US should be switched off. ① ❶: Place the sliding switch of the main unit BETM on the position OFF ❷: Place the sliding switch of the expansion unit BETM located on top left on the position ❸: Place the sliding switch of the expansion...

  • Page 19: Sensor Mounting

    For US, it is recommended to use a handheld SDT device such as the SDT340. Using a RSN (Resonant Sensor Needle) probe or a RST probe with a magnetic base, the manipulation consists in finding the place where the signal is the strongest.

  • Page 20: Display

    The dimensions are summarized in the following drawing: Figure 28: Dimensions for sensor mounting 3. Display Figure 29: Display The Online4US integrates a 5” 800x480px resistive touchscreen color LCD for Human Machine Interface (HMI) control. For more information concerning the HMI see part 20/75...

  • Page 21: Mechanical Enclosure Installation

    Output: 24VDC – 2500 mA – 60 W. Note 1: any power supply with the same characteristics can be used. Note 2: Online4US can also be directly powered from a 60W 24VDC power supply. Figure 31: Provided power supply 21/75...

  • Page 22: Online4Us Configurator

    Online4US User Manual 6. Online4US configurator The address of the Online4US configurator is: https://www.sdtultrasound.com/Online4USConfigurator/index.php?lang=en Online4US configurator is a web tool used to easily configure the Online4US according to the application needs. Step 1 Choice between coated steel and stainless-steel cabinet.

  • Page 23: Step 4

    • Two DO modules are required for 17 to up to 32 sensors. Step 4 SDT communication modules are not available yet. For a list of industrial communication modules compatible with the Online4US please contact your provider. Step 5 Indicates the power supply.
  • Page 24 Online4US User Manual Figure 34: Completed, active and non-completed steps 24/75...

  • Page 25: Part 2: Firmware

    1.1. Available groups Online4US manages 8 groups. The user may choose to use one or more of the 8 groups at his/her convenience. It is not required to follow the chronological order of the groups. Figure 35: Home screen. Groups 1 and 3 are used 1.2.
  • Page 26 Online4US User Manual Meas. start Meas. stop Sensor 1 Sensor 2 Sensor 3 Periodicity Figure 37: The monitoring scheme is common to all sensors assigned to a group 1.3.1. Input and output assigned to a group One digital input and one analog input are assigned to each group.
  • Page 27 Online4US User Manual DO 15 GROUP 8 DI 8 AI 8 DO 16 Figure 39: Overview of DI, AI and DO assigned to their respective GROUP Legend: DI = Digital Input AI = Analog Input DO = Digital Output 27/75...

  • Page 28: Block Diagram Of Menus And Sub Menus

    Online4US User Manual 2. Block diagram of menus and sub menus Home screen Measurement details Trend curve screen Password Debug mode Settings Memory management Info screen Figure 40: Block diagram of menus and sub menus 28/75...

  • Page 29: Setting Screen Overview

    Online4US User Manual Setting screen overview Channel 1/16 assignment Channel 17/32 assignment Monitoring scheduling AI & DI settings Alarm settings Alarm value edition SMS settings Save amendments Scan sensor modules Go back to Home screen Figure 41: Setting screen overview...
  • Page 30 Online4US User Manual 2.1.1. Channel assignment From the Home screen, press the parameter icon. ① ❶: An intermediate window asks for your password (default is 159753) Figure 42: Password typing If the password is correct, the main setting screen is displayed.
  • Page 31 Online4US User Manual ① ② ❶: Press the group in which you want to assign your channel ❷: Press the zone above the desired channel ❸: The zone turns to the color of the associated group ③ ❹: If needed, press the right arrow to assign channels 17 to 32 ❺: When channel assignment is completed,...

  • Page 32: Alarm Settings

    Online4US modifies the color code of the group, the color code of the measurements and the digital output status only when the alarm delay set point is reached.
  • Page 33 Online4US User Manual Set point = 3 Group 1 Figure 48: Working principle of the alarm delay behavior Legend: W is the alarm delay counter for the warning alarm level D is the alarm delay counter for the danger alarm level The following table indicates for each reading: •...
  • Page 34 Online4US User Manual 2.2.2. Alarm condition Alarm condition set point is defined per channel. The alarm definition is the combination of the 4 condition indicators using boolean connectors . When a reading fulfills the alarm condition, the alarm delay counter is incremented.
  • Page 35 Online4US User Manual 2.2.4. Alarm condition settings From the setting screen, press the alarm icon: ③ To select one channel: ❶: Press the left arrow ④ ❷: Press the right arrow ❸: The selected channel is shown on the top left of the window ❹: Press the threshold parameter icon of the...
  • Page 36 Online4US User Manual ⑨ ❾: Enter the desired value Figure 55: Entering the danger value ❿: Save the alarm threshold using the save icon ⑩ Figure 56: Saving alarm thresholds ⓫: Save the alarm condition using the save icon ⑪...
  • Page 37 The danger threshold can be lower than the warning threshold (the Online4US processes both alarm levels separately). 2.2.5. Condition indicator combination Online4US provides the opportunity to combine the condition indicators using boolean operators AND and OR. The following procedure assumes a first indicator is already used: ①...
  • Page 38 ② ❸: Enter the PIN CODE number of the sim ③ card ④ ❹: Enter an Online4US ID (used when several ⑤ Online4US are sending a SMS to the same recipient. The SMS format will be ‘’danger (or ⑥ warning) group x Online4US id xxxxxx’’...
  • Page 39 Online4US User Manual ❺: Use the test button to verify that the setting is correct ❻: Save the setting 2.2.8. Digital outputs Digital outputs can be used to externally communicate the state of the alarm and have an AON (All- Or-Nothing) behavior with two states: •...

  • Page 40: Monitoring Schedule

    Online4US User Manual GROUP 1 GOOD WARNING DANGER DO 1 DO 2 DO 1 DO 2 DO 1 DO 2 Warning Warning Warning Danger Danger Danger Figure 63: States of digital outputs for Group 1 according to the alarm status...
  • Page 41 Online4US User Manual A measurement can be triggered using: A digital input: ❻: Turn the digital input switch to ON ⑨ ⑧ ⑥ ❼: Select if the measurement starts when ⑦ the digital input status is high (closed) or low (open) ⑩...
  • Page 42 2.3.2. Periodicity: continuous When the periodicity is set to continuous: • Online4US realizes a first data acquisition; • When finished, the CPU/CUM retrieves the condition indicators, refreshes the alarm status of the group, triggers digital outputs, check the status of inputs. These operations take a few milliseconds;...
  • Page 43 Online4US User Manual 2.3.4. Digital inputs: AON mode AON (All-Or-Nothing) mode takes into consideration two states. It has a binary behavior: • All, or 1, or On; • Nothing, or 0, or Off. This mode is useful for machineries whose operation is intermittent: their health status evaluation must be performed only when running.

  • Page 44: Home Screen Overview

    Online4US User Manual 3. Home screen overview Home screen Measurement details Trend curve screen Password Debug mode Settings Memory management Info screen Figure 72: Home screen overview 44/75...

  • Page 45: Home Screen

    Online4US User Manual 3.1. Home Screen ❶: Display the machine health status of the 8 groups. The color code is: • Grey: the group is not used • Green: no triggered alarm • Orange: the warning alarm level is ①...
  • Page 46 Online4US User Manual ❶: Readings are in green when values have not triggered an alarm ❷: Readings are in red when values have triggered their danger alarm level ❸: Readings are in orange when values have triggered their warning alarm level ①...

  • Page 47: Info Screen Overview

    Online4US User Manual 4. Info screen overview Change velocity unit to mm/s or ips Modify date and time Shutdown the display (power saving mode) Recalibrate the touch screen Change the password Go to ethernet configuration menu Go back to the home screen Figure 78: Info screen overview 4.1.

  • Page 48: Memory Management Screen Overview

    Configure net bios name (used when multiple Online4US are on the same network) Set DHCP client ON or OFF Set Online4US static IP (when DHCP client is OFF) Set UDP port used to send/receive data Save ethernet configuration Figure 81: Ethernet menu Part 3: Communication for more detailed communication information.
  • Page 49 Note: • Firmware files should be located in “U0:/O4US/Firmware/” (where “U0” is the letter or the name used for the USB memory stick). Figure 84: CPU/CUM The last firmware can be downloaded from SDT ftp. The address is http://ftp.sdt.be/pub/Software/Online4US/ 49/75...
  • Page 50 From the memory management screen, press the trash bin icon. During the process, the icons update, Copy-to-USB, and trash bin are yellow. 4.2.5. Content transferred from Online4US internal memory to a USB stick The following tree hereafter shows the content of the USB stick after a transfer on a computer: Figure 86: Content of Online4US data transferred on a USB stick The files are "CSV"...
  • Page 51 These files can be edited within any notepad software in order to configure the Online4US alarm and triggering without using the Online4US display (to be sure to use the correct syntax for the files, it is recommended to copy the files from the Online4US first and then editing them).
  • Page 52 Online4US User Manual Alarm file The columns designate respectively: • Sensor ID (1 to 32); • Logic condition 1: logic operator used for the second condition indicator 0 = not used; 1 = AND; 2 = OR. • Logic condition 2: logic operator used for the third condition indicator;...
  • Page 53 Online4US User Manual The columns designate respectively: • Group ID (1 to 8); • Acquisition time: time, in seconds, used by each sensor within the group to compute their RMS value (1 to 120); • Acquisition delay: time, in seconds, minutes or hours, between each measurement (0 to 120);...

  • Page 54: Debug Screen

    The debug mode allows to verify the status of digital inputs and to manually force the status of digital outputs to ON or OFF. This mode is useful for verifying the correct input/output wiring between Online4US and a PLC or a SCADA system. From the home screen, press the debug icon: ❶: Use the scan function to refresh the...

  • Page 55: Recommended Steps Throughout Initial Online4Us-Acm Settings

    Online4US User Manual 5. Recommended steps throughout initial Online4US- ACM settings As every situation is unique, the following recommendations should not be considered as the universal way to efficiently start a permanent monitoring. Many parameters influence them. Historical data, criticality, machine type and age, spare part availability, Mean-Time-To-Repair are some.

  • Page 56: Part 3: Communication

    Online4US User Manual Part 3: Communication 1. Communication The Online4US can communicate through 3 serial communication lines: • RS-232; • RS-485; • Ethernet. The communication protocol is OSC (Open Sound Control): http://opensoundcontrol.org/ 2. Specifications 2.1. RS-232 38400-8EI Speed: 38400 bauds...

  • Page 57: Protocol

    3. Protocol 3.1. Measures The protocol used by the Online4US is OSC. Each time a measurement is done by a sensor, the Online4US send the 4 indicators values through the serial lines. The data sent use the following OSC format: /INDICATOR,ii<CH><VAL><ALARM>...

  • Page 58: Commands

    Type: sensor type, 0 = unknown sensor – 1 = US sensor – 2 = VIB sensor; • Group ID: sensor group ID, range 0 to 8 – 0 = no group assigned. 3.2.4. /SCAN Send a scan request to the device (the Online4US will do an internal scan refresh). 58/75...
  • Page 59 Online4US User Manual 3.2.5. /GAIN?,i,<Sensor ID> Get specific sensor gain information. Parameters: • Sensor ID: sensor ID (range = 1 to 32). Response from Online4US: /GAIN,ii,<Sensor ID><Gain> Parameters: • Sensor ID: sensor ID; • Gain: sensor gain. 3.2.6. /GAIN,ii,<Sensor ID><Gain>...
  • Page 60 Alarm status: 1 = no alarm – 2 = warning alarm – 3 = danger alarm – 4 = warning alarm & danger alarm. 3.2.13. /GROUP_ALARM,ii,<Group ID><Alarm Status> This message is sent by the Online4US each time a group alarm status is modified. Parameters: •...
  • Page 61 Danger Alarm – 4 = Warning Alarm & Danger Alarm. 3.2.15. /SENSOR_ALARM,iiiiii,<Sensor ID><Global Alarm Status><RMS Alarm Status><SUB RMS Alarm Status><Peak Alarm Status><Crest Factor Alarm Status> This message is sent by the Online4US each time a sensor global alarm status is modified. Parameters: •...
  • Page 62 Get Online4US group measurement information. Parameters: • Group ID: Group ID, range 1 to 8. Response from Online4US: /TRIGGER,iiiiiiiii,<Group ID> <Acquisition time> <Input State> <Digital Input Level> <Analog Input Threshold> <Analog Input Tolerance> <Continuous measurement> <Acquisition Delay> <Acquisition Type> Parameters: •...
  • Page 63 3.2.20. /ALARM?,i,<Sensor ID> Get Online4US Sensor alarm parameters. Response from Online4US: /ALARM,iiiiiiiiiiiiiiiii,<Sensor ID> <Alarm Data 1> < Alarm Data 2> < Alarm Data 3> < Alarm Data 4> <Alarm Condition 1> <Alarm Condition 2> <Alarm Condition 3> <Warning Threshold 1> <Warning Threshold 2> <Warning Threshold 3> <Warning Threshold 4>...

  • Page 64: Alternative

    The anybus communicator allows the use of multiple communication protocols in order to access the Online4US data. This communicator can be connected to the Online4US RS232/RS485 connector and is used to convert the Online4US protocol to others standard protocol used by PLCs.
  • Page 65 Online4US User Manual In this document we discuss the specific case of accessing data using Modbus TCP but the way to do is the same for other protocols. 4.1.1. Configuration 1) Connect the anybus configuration port to a computer; 2) Open the anybus application (available on anybus website): Communicator RS232-422-485;...
  • Page 66 Online4US User Manual 4) In the communicator RS232/422/485 device select generic data mode for the protocol mode; 5) In the subnetwork device, enter the communication settings (between the Online4US and the anybus): 38400-8E1. 66/75...
  • Page 67 Online4US User Manual Now we need to specify the message structure sent by the Online4US to the anybus. The Online4US is a node inside the anybus subnetwork. For each message sent by the Online4US we use a “transaction consume”. The transaction consume will contain all bytes that need to be decoded for a specific message.
  • Page 68 Online4US User Manual 68/75...
  • Page 69 Online4US User Manual The same operation needs to be done for all the message characters (“/RMS,ii” and the 0 padded). The next 8 bytes, <CH> and <DATA> correspond to the data we need to save into the anybus memory in order to have them accessed by the user. For these values we use a “Data” element.
  • Page 70 Online4US User Manual Then we need to specify the data length (4 bytes) and the data location (inside the anybus memory). The first value can be stocked at address 0. The second value (sensor measurement value) can be stocked at address 4.
  • Page 71 It is also possible to specify a trigger byte for each transaction consume. This allows the user to check the trigger byte in order to know if a new message was received. We can add more transaction consume to decode all messages that is sent by the Online4US. 71/75...
  • Page 72 Online4US User Manual Finally, we need to connect the computer to the anybus and load the configuration file. To monitor the node, right click and the node and click sur monitor. 72/75...
  • Page 73 Online4US User Manual All data received are now mapped into the anybus memory. 73/75...
  • Page 74 Online4US User Manual Now we can connect the anybus through the LAN, using the IP configured, and access the data via Modbus. For this example, the anybus is configured with the IP 192.168.2.21/24 and using a simple free Modbus test software (RMMS).
  • Page 75 Online4US User Manual 75/75...
