Channel Mode - ADJ EVENT BAR PRO User Manual

DMX
CHANNEL
VALUES
000 - 007 Blackout
008 - 037 Show 1
038 - 067 Show 2
068 - 097 Show 3
098 - 127 Show 4
1
128 - 157 Show 5
158 - 187 Show 6
188 - 217 Show 7
218 - 247 Show 8
248 - 254 Random Show
255
2
000 - 255
Note:
• When Channel 1 is set to a value between 008 - 254, Channel 2 will control the show speed.
• When Channel 1 is set to a value of 255, Channel 2 will control the sound sensitivity.

2 CHANNEL MODE

FUNCTION
Shows
Sound Active
Show Speed/Sound Sensitivity
Show Speed, slow to fast
Sound Sensitivity, least sensitive to most sensitive
15
