ADJ EVENT BAR PRO User Manual page 19

DMX
CHANNEL
VALUES
000 - 255 Pan (Head 1)
1
000 - 255 Pan Fine (Head 1)
2
000 - 255 Tilt (Head 1)
3
000 - 255 Tilt Fine (Head 1)
4
000 - 255 Head 1 Dimmer, 0% - 100%
5
000 - 255 Pan (Head 2)
6
000 - 255 Pan Fine (Head 2)
7
000 - 255 Tilt (Head 2)
8
000 - 255 Tilt Fine (Head 2)
9
000 - 255 Head 2 Dimmer, 0% - 100%
10
000 - 255 Pan (Head 3)
11
000 - 255 Pan Fine (Head 3)
12
000 - 255 Tilt (Head 3)
13
000 - 255 Tilt Fine (Head 3)
14
000 - 255 Head 3 Dimmer, 0% - 100%
15
000 - 255 Pan (Head 4)
16
000 - 255 Pan Fine (Head 4)
17
000 - 255 Tilt (Head 4)
18
000 - 255 Tilt Fine (Head 4)
19
000 - 255 Head 4 Dimmer, 0% - 100%
20
000 - 255 Master Dimmer, 0% - 100%
21
000
22
001 - 005 Reset
006 - 255 Strobing, slow to fast
25 CHANNEL MODE
FUNCTION
Strobe
Open
CONTINUED ON NEXT PAGE
19
