- Page 1 PORTABLE PLATE/BARBELL TREE PBTREEv4 401373 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
- Page 2 PARTS DIAGRAM / EXPLODED VIEW...
- Page 3 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION UPRIGHT POST UPRIGHT POST BASE BRACKET BASE TUBE HEX BOLT M12X80 FLAT WASHER 12 HEX NUT M12 SPRING WASHER 12 WEIGHT TUBE PLASTIC LINING WEIGHT TUBE END CAP (10) UPRIGHT POST END CAP (11) 2.5”...
- Page 4 ASSEMBLY INSTRUCTIONS STEP 1: SETTING UP THE BASE 1. Attach UPRIGHT POST BRACKET (2) to the 2 sides of the BASE TUBE (3), using HEX BOLT M12X80 (4), FLAT WASHER 12 (5), SPRING WASHER 12 (7) AND HEX NUT M12 (6). The order of assembly is to insert HEX BOLT M12X80 (4) through these parts, and then place FLAT WASHER 12 (5), SPRING WASHER 12 (7) and HEX NUT M12 (6) onto the end of the bolt.
- Page 5 ASSEMBLY INSTRUCTIONS STEP 2: SETTING UP THE UPRIGHT POST 1. Attach UPRIGHT POST (1) to the mounting bracket of UPRIGHT POST BRACKET (2) using HEX BOLT M12X80 (4), FLAT WASHER 12 (5), SPRING WASHER 12 (7) and HEX NUT N12 (6). The order of assembly is to insert HEX BOLT M12X80 (4) through these parts, and then place FLAT WASHER 12 (5), SPRING WASHER 12 (7), and HEX NUT M12 (6) onto the end of the bolt.
- Page 6 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 7 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
