PLATE LOADED CHEST PRESS MACHINE
PLCHSTPRS1-PLCHSTPRS2
400788
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLCHSTPRS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Titan Fitness PLCHSTPRS1

Summary of Contents for Titan Fitness PLCHSTPRS1

  • Page 1 PLATE LOADED CHEST PRESS MACHINE PLCHSTPRS1-PLCHSTPRS2 400788 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
  • Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION LEFT UPRIGHT FRAME (39) FOOT PAD RIGHT UPRIGHT FRAME (40) RUBBER CUSHION 100*50*25 LEFT HANDLE FRAME (41) END CAP Φ25*2.5 RIGHT HANDLE FRAME (42) RUBBER MAT 45*35*8 UPPER CONNECTING FRAME (43) HOLLOW SLEEVE LOWER CONNECTING FRAME (44) WASHER Φ34*Φ13*4...
  • Page 3 (20) BACK CUSHION (58) BEARING 6004ZZ (21) HANDLEBAR GRIP (59) FLAT WASHERΦ9*Φ16*1.6 (22) (60) HEX BOLT M10*25 BACK CUSHION ADJUSTABLE (23) (61) SPRING WASHERΦ10 FRAME (24) SEAT CUSHION PLATE (62) HEX BOLT M10*60 SEAT CUSHION ADJUSTABLE (25) (63) HEX BOLT M8*20 FRAME (26) SHAFT...
  • Page 4 ASSEMBLY INSTRUCTIONS STEP 1 1. Remove the Hex Bolt M8*20 (54), insert Adjustable Frame (12) into Adjustable outer Frame (13), fixing by Hex Bolt M8*20(54). 2. Assemble Front foot frame (14) and Adjustable Frame (12), using Hex Bolt M8*25 (68) and Flat washer Φ9*Φ16*1.6 (59).
  • Page 5 ASSEMBLY INSTRUCTIONS STEP 2 Connect the Left Upright Frame (1), Right Upright Frame (2), Upper Connecting Frame (5) and Lower Connecting Frame (6), using Hex Head Bolt M10x70 (50), Flat WasherVΦ11*Φ20*2 (48), Big Washer Φ10.6*Φ26*2 (53) and M10 Lock Nut (49). DO NOT TIGHTEN BOLTS AND NUTS.
  • Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Assemble the Adjustable Frame (12) to the Lower Connecting Frame (6), using Hex Head Bolt M10x70 (50), Flat WasherΦ11*Φ20*2 (48), Big Washer Φ10.6*Φ26*2 (53) and M10 Nut (49). USING RIGHT TOOLS TIGHTEN BOLTS PROPERLY.
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 4 Connect the Left Support Frame (72) on the Left Upright Frame (1), useing Hex Head Bolt M8x95 (64), Flat Washer Φ11*Φ20*2 (48), Big Washer Φ10.6*Φ26*2 (53) and Nut M10 (49). REPEAT THE ABOVE STEP ON THE OTHER SIDE.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 5 Assemble Left Connecting Frame (10) and Right Connecting Frame (11) to the Adjustable Frame (12), using Hex Bolt M10*60 (62), Nut M10 (49), Flat Washer Φ11*Φ20*2(48). Fixing the Left connecting frame (10) to the Left Upright Frame (1), using Hex Head Bolt M8x95 (64), Flat WasherΦ11*Φ20*2(48), Big Washer Φ10.6*Φ26*2 (53) and Nut M10 (49).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 6 Assemble the Weight Plate Holder (17) to the Left & Right upright frame (1 & 2), using Hex Head Bolt M10x25 (60), Φ10 Spring Washer (61), Flat WasherΦ11*Φ20*2 (48). Remove the Hex Bolt M8*20 (54), Insert the Limited Frame (9) into the Left & Right upright frame (1 &...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7 Assemble the Weight Plate Holder (17) and Left Handlebar (7) to the Left Handle Frame (3), using Hex Head Bolt M10x70 (50), Hex Head Bolt M10x25 (60), Φ10 Spring Washer (61), Flat Washer Φ11*Φ20*2 (48), and Lock Nut M10 (49).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 8 Assemble the Weight Plate Holder (17) and Right Handlebar (8) to the Right Handle Frame (4), using Hex Head Bolt M10x70 (50), Hex Head Bolt M10x25 (60), Φ10 Spring Washer (61), Flat WasherΦ11*Φ20*2 (48), and Lock Nut M10 (49).
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 9 Fixing the Left Handle Frame (3) and Right Handle Frame (4) to the Left Upright Frame (1) and Right Upright Frame (2), using Hex Head Bolt M8x15 (58), Flat WasherΦ9*Φ24*2 (52).
  • Page 13 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
  • Page 14 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2022 Titan Brands...
