60-INCH RONIN PLYOMETRIC MACHINE

PLYMACH60-1 - PLYMACH60-2

412217

Operator's Manual

Read the Operator's Manual entirely. When you see this

symbol, the subsequent instructions and warnings are

serious follow without exception. Your life and the lives

of others depend on it!

Need help?

Do you have a question about the PLYMACH60-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Fitness PLYMACH60-1

Page 1 60-INCH RONIN PLYOMETRIC MACHINE PLYMACH60-1 - PLYMACH60-2 412217 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
Page 2 PARTS DIAGRAM / EXPLODED VIEW...
Page 3 DESCRIPTION DESCRIPTION (35) BASE RUBBER BUMPER (36) TOP BEAM SMALL RUBBER SLEEVE (37) LEFT UPRIGHT METAL SLEEVE (38) RIGHT UPRIGHT Φ50 PULLEY (39) LEFT HANDGRIP GUIDE ROD BUSHING (40) RIGHT HANDGRIP BEARING 61901ZZ (41) LANDING PAD HEX BOLT M8*55 (42) WEIGHT PLATE SUPPORTER HEX BOLT M10*25 (43)
Page 4 ASSEMBLY INSTRUCTIONS STEP 1 1. Fix the SMALL RUBBER SLEEVES (36) on the LEFT UPRIGHT (3), RIGHT UPRIGHT (4), using COUNTERSUNK HEAD SCREW M6*15 (48). 2. Connect LEFT UPRIGHT (3), RIGHT UPRIGHT (4) and LANDING PAD (7), through the PULL TABS (9), PULL RODS (13) and LANDING PAD (7), and lock into the first hole position.
Page 5 ASSEMBLY INSTRUCTIONS STEP 2 1. Connect LEFT UPRIGHT (3), RIGHT UPRIGHT (4) and TOP BEAM (2), using FLAT WASHER Φ11*Φ20*2 (57), SPRING WASHER Φ10 (54), and HEX BOLT M10*25 (42). 2. Install the terminal of CABLE (18) on the LANDING PAD (7), using FLAT WASHER Φ11*Φ20*2 (57) and COUNTERSUNK HEAD SCREW M10*20 (49).
Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Connect LEFT UPRIGHT (3), RIGHT UPRIGHT (4) and BASE (1), using FLAT WASHER Φ11*Φ20*2 (57), SPRING WASHER Φ10 (54), and HEX BOLT M10*25(42).
Page 7 ASSEMBLY INSTRUCTIONS STEP 4 1. Connect LEFT HANDGRIP (5), RIGHT HANDGRIP (6) and BASE (1), using FLAT WASHER Φ11*Φ20*2 (57), SPRING WASHER Φ10 (54), and HEX BOLT M10*25 (42). 2. Connect the other side of LEFT HANDGRIP (5), RIGHT HANDGRIP (6) and TOP BEAM (2), using FLAT WASHER Φ11*Φ20*2 (57), M10 NUT (60), and HEX BOLT M10*80 (44).
Page 8 ASSEMBLY INSTRUCTIONS STEP 5 1. Insert the GUIDE ROD (22) on the BASE (1). 2. Insert the WEIGHT PLATE (23) into the GUIDE ROD (22), then fixing the GUIDE ROD (22) on the TOP BEAM (2), using GUIDE ROD BUSHING (39) and SCREW M8*8 (63).
Page 9 ASSEMBLY INSTRUCTIONS STEP 6 Install the GRID GUARD FRAMES (24) on the GRID GUARD (25). PLEASE PAY ATTENTION THE DIRECTION.
Page 10 ASSEMBLY INSTRUCTIONS STEP 7 1. Insert HEX BOLT M8*35 (65) and FLAT WASHER Φ9*Φ16*1.6 (56) through the GRID GUARD FRAME (24) and the long hole on the TOP BEAM (2) in turn, then fix in the threaded hole on the shorter side of TENSION FRAME (26). 2.
Page 11 ASSEMBLY INSTRUCTIONS Step 8 Install the FOAM (27) on the TOP BEAM (2). After adjustment, use magic buckle to fix. Opening...
Page 12 ASSEMBLY INSTRUCTIONS STEP 9 Connect the REAR SUPPORT FRAME (10) and BASE (1), using FLAT WASHER Φ11*Φ20*2 (57), M10 NUT (60) and HEX BOLTM10*90 (45).
Page 13 ASSEMBLY INSTRUCTIONS STEP 10 Put the machine in place, fixing on the floor by EXPANSION ANCHOR BOLT M10*70 (68).
Page 14 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...

This manual is also suitable for:

Plymach60-2 412217
