Using This Manual - Fluke CableAnalyzer DSP-4000 Series User Manual

DSP-4000 Series
Users Manual

Using This Manual

Before using the test tool, carefully read "Safety and
Operational Information" at the beginning of Chapter 2.
Except where noted, the information in this manual applies to all DSP-4000 Series
test tools.
If you are familiar with the general features, functions, and operation of LAN
cable testers and want to start testing cables immediately, proceed as follows:
1. Read "Quick Start" in Chapter 2 to prepare the test tool for operation, access
the test tool's functions, and run an Autotest.
2. Refer to the test and setup features listed under "Rotary Switch" in Chapter 2
to locate functions in the test tool's menu structure.
3. Refer to the Glossary in the Appendix to find definitions for unfamiliar terms.
If you have never used a LAN cable tester, but want to start testing cables
immediately and learn as you work, proceed as follows:
1. Read "Quick Start" in Chapter 2 to prepare the test tool for operation, access
the test tool's functions, and run an Autotest.
2. Refer to the Glossary in the Appendix to find definitions for unfamiliar terms.
3. Refer to the test and setup features listed under "Rotary Switch" in Chapter 2
to locate functions in the test tool's menu structure.
4. Refer to Chapter 3, "Autotest," to find more detailed information about cable
tests and test results.
5. Read Chapter 4, "Running Individual Tests," to learn how to run individual
tests and monitor network traffic and impulse noise.
6. Read Chapter 7, "Basic Cable Testing," to add to your cable testing and
troubleshooting knowledge.
