Self-testing mode
FUN=ON (the 10th dip switch=ON)
1-9=off 1=on
Dip Switch
Self-test
Static
Black
Function
4 5 6 7 8 9 10
1 2 3
Static Static
Green Yellow
Static Static Static
Red Blue Purple
[Attn] When several dip switches are on, subjected to the highest switch value.
As the figure above shows, the effect will be 7 color gradient at 7 speed level.
DMX dimming instruction
Each LT-904 DIP DMX decoder occupied 4 DMX -
addresses when connecting the DMX console.
E.g., the defaulted initial address is 1, please
find their corresponding relationships in the form.
Self-testing Mode
2=on 3=on
Static Static Static
Red Green Blue
Static 7 Color
Cyan Jumping
Static
7 Color
White Gradient
4=on 5=on 6=on
Static Static
Static
Yellow Purple Cyan
OFF
ON
For changing effects (Dip Switch 8 9=on):
DIP switch 1-7 is used to realize 7 speed
levels. (7=on, the fastest level)
DMX Console
CH1 0-255
CH2 0-255
CH3 0-255
CH4 0-255
5
7=on 8=on 9=on
Static 7 Color
7 Color
White
Jumping
Gradient
/
DMX Decoder
CH1 PWM 0-100% (LED R)
CH2
PWM 0-100% ( LED G)
CH3
PWM 0-100% ( LED B)
CH4
PWM 0-100% ( LED W)
