- Page 1 User Guide Type 8870 High Frequency Linear Array Transducer INSERT IMAGE English BB1980-B For Professional Users Only June 2012...
- Page 2 If you receive an email message from us asking for your feedback, we hope you will be willing to answer some questions about your experience buying and using our products. Your opinions are important to us. You are of course always welcome to contact us via your BK Medical representative or by contacting us directly.
-
Page 3: Table Of Contents
Contents Introduction ............5 Scanning Plane . -
Page 5: Introduction
Introduction This is the user guide for High Frequency Linear Transducer Type 8870 and must be used together with Care, Cleaning & Safety which contains important safety information. 8870 is suitable for a wide range of small part and musculoskeletal studies and for vascular examinations. -
Page 6: Service And Repair
Service and Repair WARNING Service and repair of BK Medical electromedical equipment must be carried out only by the manufacturer or its authorized representatives. BK Medical reserves the right to disclaim all responsibility, including but not limited to responsibility for the operating safety, reliability and performance of equipment serviced or repaired by other parties. -
Page 7: Starting Scanning
Gel also creates a good acoustic contact between the skin and the transducer; therefore, apply a small amount to the outside of the cover prior to scanning. Re- apply the gel frequently to ensure good screen images. 8870 User Guide (BB1980-B) -
Page 8: Using The Transducer Control Button
To change the orientation of the image on the monitor, refer to the applicable scanner user guide for instructions. Puncture Facilities Puncture and biopsy is possible with Type 8870 transducer. The puncture attachment is illustrated in the following pages with a brief description of its use and operating instructions. - Page 9 Loosen screw C. Insert needle. Tighten screw C until the needle is held firmly. Figure 3. Puncture attachment UA1251. All parts of the puncture attachment can be autoclaved or disinfected by immersion in a suitable solution. 8870 User Guide (BB1980-B)
-
Page 10: Performing Puncture And Biopsy
Figure 4. Type 8870 with puncture attachment UA1251 mounted. Performing Puncture and Biopsy WARNING It is essential for the patient’s safety that only the correct puncture attachments, as described in this guide, are used. Never use unauthorized combinations of transducers and puncture attachments or other manufacturers puncture attachments. -
Page 11: Cleaning After Puncture And Biopsy
When performing a biopsy, always make sure that the needle is fully drawn back inside the needle guide before moving the probe. Figure 5. Puncture lines for UA1251 with Type 8870. The transducer and puncture attachment can be removed without disturbing the position of the needle during puncture. - Page 12 WARNING For contaminated disposals such as transducer covers or needle guides, follow disposal control policies established for your office, department or hospital. June 2012 8870 User Guide (BB1980-B)
- Page 14 LEGAL MANUFACTURER : BK Medic al ApS , Milepa rken 34, 2730 Herlev, Denma rk. Tel.: +45 44528100 Fax : +45 44528199 E mail: info@bkmed.dk...
