Summary of Contents for BK Medical 8808e
- Page 1 User Guide Type 8808e Prostate Biplane Transducer English BB1856-F March 2017 For Professional Users Only...
- Page 2 If you receive an email message from us asking for your feedback, we hope you will be willing to answer some questions about your experience buying and using our products. Your opinions are important to us. You are of course always welcome to contact us via your BK Medical representative or by contacting us directly.
-
Page 3: Table Of Contents
Imaging with Type 8808e ........ -
Page 5: Introduction
Introduction This is the user guide for Prostate Biplane Transducer Type 8808e and must be used together with Care and Cleaning which contains important safety information. Indications for Use Prostate Biplane Transducer Type 8808e is designed for transrectal prostate imaging. -
Page 6: Service And Repair
Service and Repair WARNING Service and repair of BK Medical electromedical equipment must be carried out only by the manufacturer or its authorized representatives. BK Medical reserves the right to disclaim all responsibility, including but not limited to responsibility for the operating safety, reliability and performance of equipment serviced or repaired by other parties. -
Page 7: Starting Imaging
Re-apply the gel frequently to ensure good screen images. WARNING Use only water-soluble agents or gels. Petroleum or mineral oil-based materials may harm the cover materials. 8808e User Guide (BB1856-F) Starting Imaging... -
Page 8: Using The Transducer Control Button
Imaging with Type 8808e Simultaneous Biplane Imaging 8808e can transmit transverse (T) and sagittal (S) images simultaneously. When you press the system’s Split key, simultaneous imaging is automatically activated. Transverse or Sagittal Imaging Click Simultan to toggle simultaneous imaging on or off. When simultaneous... -
Page 9: Imaging Without Puncture Or Biopsy
(see Figure 3). Figure 3. Type 8808e and the dummy channel bracket UA1325. Note: The dummy bracket must be removed before 8808e is prepared for disinfection. The bracket can be disinfected using the same methods as explained later under UA1326. - Page 10 Please refer to Care and Cleaning for an example of how to open a sterile-packed product. Simultaneous Biplane The sterile biopsy guide UA1322-S, UA1322-S14 and reusable biopsy guide UA1326 are used for simultaneous biplane imaging. Figure 4. Reusable biopsy guide UA1326. March 2017 8808e User Guide (BB1856-F)
- Page 11 The puncture line for UA1322-S, UA1322-S14 and UA1326 on 8808e is shown in Figure 5. UA1322-S and UA1326 have a bore diameter of 1.6 mm, suitable for 17- gauge needles. UA1322-S14 has a bore diameter of 2.1 mm, suitable for 14-gauge needles.The puncture line is angled at 19°...
-
Page 12: For Transperineal Puncture
The puncture attachment should be correctly positioned so that the groove slides easily over stud. No force should be used when attaching the puncture attachment to the transducer. Figure 8. Puncture attachment UA1324 mounted on 8808e. March 2017 8808e User Guide (BB1856-F) -
Page 13: Performing Puncture And Biopsy
The puncture lines for UA1324 on 8808e are shown in Figure 9. Figure 9. Illustration of the puncture line for puncture attachment UA1324. Performing Puncture and Biopsy WARNING It is essential for the patient’s safety that only the correct puncture attachments, as described in this guide, are used. -
Page 14: Cleaning After Puncture And Biopsy
See the applicable system user guide for further details. WARNING For contaminated disposals such as transducer covers or needle guides, follow disposal control policies established for your office, department or hospital. March 2017 8808e User Guide (BB1856-F)
