Installation; Wiring Diagram - Key Release Type 1 - Directed DB3 Installation Manual

Wiring diagram - Key Release Type 1

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Ignition Switch Connector
(at ignition switch)
(-) Starter 2: (-) Keysense: Black/Yellow, pin 5
Gray/Blue,
pin 13
(-) Starter 1: Black or Black/Blue, pin 6
(-) Starter 3:
Black/Red,
(+) Key Release:
pin 14
Gray/Yellow, pin 15
BCM
Gray/Yellow
Key Release Voltage Test
Without Push Button Start Switching the ignition on/off
•Insert the key into the ignition lock.
•Press the key briefly without pressing the clutch pedal
(for manual transmissions) or the brake pedal (for automatic
transmissions).
•To switch the ignition off, press the key again.
OR
With Push Button Start Switching the ignition on/off
•Press the START ENGINE STOP button without pressing the
clutch pedal (for manual transmissions) or the brake pedal
(for automatic transmissions)
•To switch the ignition off, press the button again.
Using a multimeter, follow the type that corresponds with the key
release wire test:
Type 1:
Follow this installation if Gray/Yellow test:
1. IGN OFF: 0 Volts
2. IGN ON: 0 Volts
Type 2:
Follow the installation on the next page if the
Gray/Yellow wire tests with the following results:
1. IGN OFF: 0 Volts
2. IGN ON: 12 Volts
6 403.AUDI02 3.10 2015 Audi A4 (Smart Key w/PTS)
©2021 VOXX•DEI LLC. All rights reserved.
Twisted pair in driver kick
panel (at door harness)
FT CAN Low: Orange/Brown
3x 1A Diodes
Refer to
'Vehicle connections'
for wire and connector
details related to the
standard connections in
the vehicle.
2x 1A
Brake switch Diodes
(at brake switch)
1
2
3
(+) Brake:
4
Red/Black, pin 3
FT CAN High: Orange/Green
HS CAN High:
Orange/Red, pin 6
OBDII
1
Diagnostic
Connector
9
HS CAN Low:
Brown/Red, pin 14
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
FT CAN High: Orange/Green: 5
FT CAN Low: Orange/Brown: 6
(+)12V Input - Type 1: Brown: 7
(+) Key Release Output - Type 1 : Yellow: 8
Key Wrap: Yellow/Red: 11
Key Wrap: Brown/Red: 12
(+) 12V Input: Red: 13
(-) Ground: Black: 14
(-) Keysense Output: Black/White: 1
(-) Starter Output: Green/Black: 2
(+) Brake Activation Output: Gray: 6
(-) PTS Output: Blue/Red: 12
ONLY for PTS vehicles
PTS Connector
(at PTS button)
(-) PTS: Blue/White,
1
pin 3
2
3
4
(-) PTS: Blue/Yellow,
pin 4
).
You can connect to either a
XL202 RFTD OR a SmartStart
8
module.
16
Refer to the SmartStart/XL202
Installation Notes for more
information.
6: White/Black:
(-) Hood
Remote Start Safety
Override Switch
These connections will be
Hood Pin
made along with the
ones from the Ignition
Switch Plug.
