Thank you for choosing our product
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children!
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced.
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
-8-
Warning
INSTALLATION GUIDE
Item No.:LTMLT2AV1
TV Size Range: 10"~27"
Max load capacity of each TV plate:
8Kg/17.64lbs
Integrated Cable management
CAUTION
Please read this guide before installation.
Ensure the correct installation. Keep away from high frequency or power equipment to
avoid disturbance.Choose desk to put this product.
We can not be responsible for any damage caused by wrong installation.
Advertisement
Related Manuals for Displays2go LTMLT2AV1
Summary of Contents for Displays2go LTMLT2AV1
- Page 1 INSTALLATION GUIDE Item No.:LTMLT2AV1 Thank you for choosing our product TV Size Range: 10"~27" Warning Max load capacity of each TV plate: This product contains small items that could be a choking hazard if swallowed. Keep 8Kg/17.64lbs these items away from young children! 1.Make sure these instructions are read and completely understood before attempting...
- Page 2 Hardware Kit: Description Tube Cover Washer (Φ8.5xΦ16x0.8) TV plate Knob Slid block Fixed wreath M5x10mm sunk bolt Tighten block Cable cover Tube Botton support Hand handle Bottom plate Mat feet M4×12mm bolt M5×12mm bolt M4X10mm bolt 3X3,4X4Wrench 6X6Wrench...
- Page 3 Part 1-Install TV plate and fixed wreath Part 4-Fitting the bottom plate(13) on the desk[If you don’t want to use bottom support(11)] First install the plastic cover, then fixed the wreath(6) on the tube by M5x10mm sunk bolt(7). Once the wreath fixed, then slide the TV plate into first, take off screw M6X10 and M10X20 by wrench,then remove the whole the tube and fixed it by knob(4).
- Page 4 Part 2-Fitting the bottom support on the desk Part 3-Attaching TV plate to screen Choose the position of the base you want installed. Make sure there is Center TV plate on back of the screen and align the eight mounting holes. enough space to spread display considering the show size.The desk should Select screws(A,B).
