- Page 3 1. Attach casters to the bottom of the frame, using a wrench 2. Slot screw down through the leg posts as shown, and use to tighten. Allen wrench to tighten down. Repeat for both legs. 4. Attach media shelf to cross bar as shown.
- Page 4 5. Insert handles into upper leg post pieces by sliding in as shown, then tightening screws to lock in desired place. 6. Insert screws into prongs, then tigten slightly, leaving slightly loose. 7. Insert prongs into lower leg post.
- Page 5 8. Tighten screws that were left loose in step 6 to lock the posts together. 9. Lock the flat panel at the desired height at which you would like to fix the crossbar that will hold the TV. 1 1. Slot cross bars that hold TV together and lock in 10.
- Page 6 12. Put TV crossbar onto flat panels and lock in place from the back of the unit, as shown. Repeat for both posts. A level is recommendded. 14. Place bracket onto the TV crossbar by fitting the notches over the bar. 13.
- Page 7 15. Fit rubber-tipped screw into bracket and tighten 15. Slot the plastic cord management unit into the leg to hold the bracket in place at desired angle. posts at desired height to hold TV cord. 18. Attach the media shelf to the back of the TV crossbar.
