Summary of Contents for Displays2go TVM110B
- Page 1 TVM110B 46-110" 76-152cm 125kg [275Ibs] Landscape VESA Max 800*600 Portrait VESA Max.400*600...
- Page 2 NOTE:Read the entire instruction manual before you start installation and assembly. WARNING Do not begin the installation until you have read and understood the instructions and warnings contained in this installation sheet. If you have any questions regarding any of the instruction or warning, please contact your local distributor.
- Page 3 2PCS 1PCS 1PCS 1PCS M5X15 M6X15 M8X15 M10X15 10X70 12X70 4PCS 4PCS 4PCS 4PCS 8PCS 8PCS 4PCS 4PCS 4PCS 12PCS 17mm 14mm 15X 8X15 1PCS 1PCS 1PCS 1PCS 1PCS 1PCS 4PCS Landscape Installation VESA MAX 800X600 www.displays2go.com...
- Page 4 Solid Brick and Concrete Block Mounting Use a level to create an even line and a drill to make pilot holes. Ensure the concrete is at least 70mm deep. www.displays2go.com...
- Page 5 Use of a stud finder is highly Installed on the wall recommended when mounting to a wall with wood studs. Use a level to create an even line and a drill to make pilot holes. Ensure the studs are at least 70mm deep. www.displays2go.com...
- Page 6 Use included spacers if you have a recessed back TV. www.displays2go.com...
-
Page 7: Flat Screen
Hook screen onto the wall plate Wire Locking System Level the flat screen by adjusting M8x200mm level adjustment screw LATERAL ADJUSTMENT BY HAND WALL FLAT SCREEN www.displays2go.com... - Page 8 V E S A M A X 4 0 0 X 6 0 0 Solid Brick and Concrete Block Mounting Use a level to create an even line and a drill to make pilot holes. Ensure the concrete is 70mm at least 70mm deep. Φ12mm Mount to the concrete wall www.displays2go.com...
- Page 9 Use a level to create an even line and a drill to make pilot holes. Ensure the studs are at least 70mm deep. Installed on the wall Use included spacers if you have a recessed back TV. www.displays2go.com...
- Page 10 Hook screen onto the wall plate Wire Locking System Level the flat screen by adjusting M8x200mm level adjustment screw LATERAL ADJUSTMENT BY HAND WALL FLAT SCREEN www.displays2go.com...
