74 Maintenance
5
4 Press down on the lower part of the
UV-C lamp, align the UV-C lamp pin with th
e upper groove, and then remove it.
5 Remove the rubber ring and insert it into the
UV-C lamp to be replaced.
6 Fit a UV-C lamp pin into the groove on the lo
wer connector and then the other one into t
he groove on the upper part of the UV-C la
mp.
7 Turn the UV-C lamp to fix it.
