Replacing UV-C Lamp

The guaranteed use hours of the UV-C lamp is 4,000 hours.
However, this is based on continuous use, and the actual life span of the lamp in the use envi
ronment may be different. It is recommended to replace the lamp every 1 to 1.5 years to mai
ntain the illumination level necessary to secure UV processing power.
Replace the UV-C lamp according to the replacement cycle or when an error occurs.
제품 규격에 명시된 램프(Philips TUV 36W/G36 T8) 로만 교체 바랍니다.
1
실사용 환경에 따라서 차이가 있을 수 있습
니다.
1
1 Remove the UV-C lamp protection net. Loos
en the two fixing screws on each of the upp
er and lower parts of the UV-C lamp protect
ion net.
2 Remove the two fixing pins from the upper a
nd lower parts of the UV-C lamp. Loosen th
e screws on the left and right of the pins fixi
ng the UV-C lamp.
3 Turn the UV-C lamp to align the pins and the
upper grooves.
Maintenance 73
